- Page 1 Operating Instructions DUSTY MINI REITEL Feinwerktechnik GmbH Senfdamm 20 | 49152 Bad Essen Phone: +49-(0)5472-9432-0 | Fax: +49-(0)5472-9432-40 www.reitel.com | info@reitel.com...
- Page 2 The suction levels of the DUSTY-series are perfectly suited for the removal of dust and contaminants at the workbench or production units in the laboratory. The DUSTY MINI with filter bag and fleece filter basket is a dry vacuum cleaner with excellent suction power and extremely quiet 62 dB(A) noise emission.
-
Page 3: Table Of Contents
INDEX EQUIPMENT ......................... 4 ....................... 4 ASIC QUIPMENT ....................4 PECIAL CCESSORIES ....................5 PERATING LEMENTS ......................6 ECHNICAL SAFETY NOTES ......................7 .................... 7 ENERAL AFETY OTES ..................... 8 PECIFIC AFETY OTES INSTALLATION ......................9 ......................9 NSTALLATION ....................9 OSE INSTALLATION .................... -
Page 4: Equipment
DUSTY MINI single workplace suction • 3,0 m suction hose • 10 m cable • Fleece filter basket (1 piece) • Filter bag (1 piece) • Fine filter fleece (1 piece) Special Accessories • Order-No.: 22905000 Filter bag DUSTY MINI (5 pieces/pack) -
Page 5: Operating Elements
Operating Elements On/off switch Inlet fitting Suction hose Handle with cable receptacle Upper section of the suction unit (light grey) Suction power control switch Retaining clamps Dirt tank (dark grey) Device view Detail 2 Detail 3 Detail 1 Inlet fitting Upper section of suction Fleece filter basket Detail 6... -
Page 6: Technical Data
Technical Data Line voltage 230 V/50–60 Hz Current consumption 1.250 W Height/width/depth 400/290/405 mm Weight 5 kg Dust collection 95 % (class M) Sound level 62 db(A) Tank volume 13 l Housing plastic Order-No.: 12900000 Made in Germany (Subject to modifications) -
Page 7: Safety Notes
Safety Notes General Safety Notes • All equipment undergoes final inspection and testing before leaving our factory. However, if equipment is damaged during shipping or through any other circumstances, it must not be used in service. Please check the device regularly for damages. Damaged parts should be replaced immediately. -
Page 8: Specific Safety Notes
Specific Safety Notes • This device is exclusively designed to pick up dry dust. • Don’t pick up any explosive, burnable or aggressive fluids or dust with the suction unit. • This suction is not suitable for picking up harmful dust, risking to damage the filter element (e.g. -
Page 9: Installation
Installation The equipment delivered is ready for immediate use. The sealed plug can be connected directly to the mains supply 230 V/16 A. For installation please refer to safety notes in chapter 2. Installation 1. Ensure that the suction is switched off with the on/off switch (1). 2. -
Page 10: Notes For The User
Notes for the User The DUSTY MINI is a silent and powerful dry suction unit. Using both fleece filter basket and filter bag, high level filtration is achieved for picking up dry substances. How to start the suction unit 1. Switch off suction with on/off switch (1). The suction’s motor starts. Now switch on power tool. -
Page 11: Troubleshooting
Troubleshooting Device cannot be switched on (motor a. Check the fuse of the building. doesn’t start). b. Overload protection is activated (switch off the suction and allow it to cool for approx. 5 minutes). Low suction capacity. a. Clogged suction hose or nozzle→ clean suction hose / nozzle. -
Page 12: Maintenance
Maintenance • Regularly check the device state. Pay attention to visible damage to housing or power cord. • Regularly replace the filter bag (see chapter 4.2 Replacing fine dust filter, filter bag and fleece filter basket). • Regularly empty or clean the fleece filter basket (see chapter 4.2 Replacing fine dust filter, filter bag and fleece filter basket). -
Page 13: Warranty
Warranty We, REITEL Feinwerktechnik GmbH, offer a 1 year’s warranty beginning from the proven date of purchase. This warranty covers all defects traceable to materials, design or workmanship. The following warranty regulations are applicable: Within the warranty period Reitel Feinwerktechnik GmbH or an authorized distributor agrees at its sole option, to perform repair or replace this product at no charge covering all defects traceable to materials, design or workmanship. - Page 14 REITEL Feinwerktechnik GmH; − The warranty does not cover the cost of removal and replacement of parts and accessories, unless supplied as original equipment by REITEL Feinwerktechnik GmbH − All kind of damages occurred not directly at the device as well as consequential damages (e.g.
- Page 15 Should you need to borrow a device while your device is being repaired, please contact Messrs. REITEL or your distributor. These loans are a service for which availability cannot necessarily be guaranteed. After the warranty period, a free may be charged for loan...
-
Page 16: Disposal Regulations
Disposal Regulations According to valid laws our devices are properly disposed of according to B2B– Regulations for proper disposal. Pls. contact your local dealer for additional information. -
Page 17: Spare Parts List
Spare Parts List Best.-Nr.: Menge Ref.: Qty. Unit E7811500 Absaugschlauch, 3 m Stck Suction hose, 3 m piece E7874200 Ring für Absaugschlauch Stck Ring for hose adapter piece E7874100 Überwurfmuffe Stck Lock brush piece E7294000 Werkzeugadapter Stck Tool Adapter piece... -
Page 18: Ec Conformity Declaration
EC Conformity Declaration... - Page 20 We manufacture in compliance with Quality Management ISO 9001:2015, incorporating established standards. REITEL Feinwerktechnik GmbH Senfdamm 20 | 49152 Bad Essen Tel.: +49-(0)5472-9432-0 | Fax: +49-(0)5472-9432-40 www.reitel.com | info@reitel.com...
