SPECIFICATIONS
Maximum Air Pressure
Maximum Fluid Pressure
Weight
Air Inlet Thread
Fluid Inlet Thread
Cheater Valve Assy.
PARTS LIST
No.
Part Number
1 MSG-368
2 Refer to Chart 2
3 Refer to Chart 2
4 GTI-425-K
6 APOLLO-72-K5
7 APOLLO-12
8 Refer to Chart 2
9 APOLLO-14-K5
10 APOLLO-16C
11 APOLLO-44C
12 APOLLO-43
13 APOLLO-463
14 APOLLO-108
15 FUN-46-K10
16 FUN-45-K5
17 APOLLO-21
18 APOLLO-42C
19 LUNA-30
20 APOLLO-35
LUNA-35
21 APOLLO-BODY-S
APOLLO-BODY-G
0.69Mpa (7 bar)
0.69Mpa (7 bar)
394g (Pressure Type / Air Cap 777)
G1/4
G3/8 (Pressure/Suction)
G1/4 (Gravity)
Standard for Gravity / Suction type (Option for Pressure)
Description
Retaining Ring
Air Cap
Fluid Tip
Baffle
Gasket Kit of 5
Gun Body Bushing
Needle
Spring Kit of 5
Adjusting Screw
Pattern Valve Assy
Air Valve Assy
Needle Packing
Trigger
Circlip Kit of 10
Bearing Stud Kit of 5
Plug (for Pressure Feed)
Cheater Valve Assy (Option)
Air Nipple G1/4
Fluid Nipple G3/8
Fluid Nipple G1/4
Gun Body
Gun Body
Qty
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
Remarks
Pressure Type Only
Pressure / Suction Type
Gravity Type
Pressure / Suction Type
Gravity Type
