GE DigitalFlow GS868 Programming Manual page 41

Entering Mass Flow Data
Procedure Options
Programming Site Data
•
If the Static Density? prompt in the
NO
is set to , the meter returns to the
•
If Static Density? is set to
10.Use the
[F1]-[F4]
keys to select the Mass Flow units, listed in
Table 1-8 below.
Table 1-8: Available Mass Flow Units
English Mass Flow Units
LB- Pounds
KLB - Thousands of Pounds
MMLB - Millions of Pounds
TONS - Tons
11.Use the
[F1]-[F4]
keys to select the Mass Flow Time units
12.Use the
[F1]-[F4]
keys to select the MDOT Decimal Digits (the
number of digits to the right of the decimal point) for displaying
mass flow.
13.Use the
[F1]-[F4]
keys to select the Mass (Totalizer) units, listed in
Table 1-8 above.
14.Use the
[F1]-[F4]
to specify the Mass Decimal Digits (the number
of digits to the right of the decimal point) for displaying totalized
mass flow.
After completing the above steps, the meter returns to the
PROGRAM
prompt. Continue as follows:
•
To continue programming the meter, refer to the menu maps in
Appendix A and navigate to the desired menu. Then, proceed to
the appropriate section of this manual for instructions.
•
To leave the User Program and retain the previous settings,
[EXIT]
press twice and then press
Any programming changes will be discarded and you will be
returned to the data display.
•
To leave the User Program and return to measurement mode,
[EXIT]
press twice and then press
Your programming changes will be entered into the meter's
memory, and you will be returned to the data display.
ADVAN (MASS
option
GLOBL
prompt.
YES
, complete the following steps.
Metric Mass Flow Units
KG - Kilograms
Tonnes - Metric Tons
[F1] = NO
at the SAVE prompt.
[F2] = YES
at the SAVE prompt.
March 2008
submenu)
.
Global
1-33
