Setting Up a Printer

Printing Data
PRNTR
Use the submenu to specify the type of printer connected to the
Model GS868. To set up a printer, refer to Figure A-6 on page A-6,
and complete the following steps:
IMPORTANT:
A printer must be properly set up before proceeding
to any of the other sections in this chapter
1. To access the Print Menu, press the
Note: The Print Menu is not protected by the security feature and a
password is never required to access this menu.
2. Press the [←] or [→] key to display the option bar shown, and
[F1]
then press to select the
3. Use the [←], [→] and
Type. See Table 4-3 below for a complete list of the available
options.
Note: For compatibility with the Model GS868, the printer must
have an RS232 serial interface. To use a printer with a
parallel interface, a serial-to-parallel adapter must be used.
Table 4-3: Available Printer Options
Key(s) Printer Type
DP411
[F1]
XTECH
[F2]
[F3] EPSON
KODAK
[F4]
[→] SP401
+[F1]
After the desired printer type has been selected, the meter returns to
the standard data display screen and normal measurement taking.
[PRNT]
key.
PRNTR
submenu.
[F1]-[F4]
keys to select the desired Printer
Description
Seiko Model DPU-411 Type II
Extech Mini Serial Printer 42
Epson or Epson-compatible
Kodak Diconix 150 Plus
Syntest SP-401
March 2008
4-9
