GE DigitalFlow GS868 Programming Manual page 11

Key
Software Function Keys - press to
select the functions displayed
directly above them in the option bar.
These keys apply only to the left pane
of the display screen.
Software Function Keys - press to
select the functions displayed
directly above them in the option bar.
These keys apply only to the right
pane of the display screen.
Shift Key - use this red key to access
the shifted function of the other keys.
One press shifts the next keystroke
only, while two presses locks the key-
pad in shifted mode. A third press
releases the shift function.
Arrow Keys - in measurement mode,
use to scroll through function choices
on the option bar. In programming
mode, use to scroll through menu
choices. The [←] also acts as a back-
space key in programming mode.
Program Key - press to enter the
User Program. See page 1-8 for
details.
Programming Site Data
Table 1-1: Model GS868 Key Functions
Unshifted Function Shifted Function
None
None
None
Use to enter the letters A, B, C and D,
respectively.
Use to enter the letter Q.
March 2008
1-3
