Monitoring

Port usage chart

To generate a Port usage chart:
1. If you have not already done so, enable IntelliFlow. See
2. From the menu, click Dashboard.
3. Click Port Usage.

Change chart view options

You can use the Chart menu to select how you want to view chart data:
To change chart view options:
1. When a chart is displayed, click
2. Select an available view for the chart.

Export chart to PNG

To export a chart to a PNG file:
1. When a chart is displayed, click
2. Select Export to PNG.
The chart is saved as a PNG file and downloaded to your PC.

Print a chart

To print a chart:
1. When a chart is displayed, click
2. Select Print chart.
3. Fill in print options and click Print.
Digi IX14 User Guide
Configure
(Chart menu).
(Chart menu).
(Chart menu).
Configure IntelliFlow
IntelliFlow.
