A P P E N D I X A C O N T I N U E D
MODBUS FUNCTION USE
03 Holding Register continued
OWDMANUAL 1114
REGISTERS
42001: Trend 1
42002: Trend 2
42003: Trend 3
42004: Trend 4
42005: Trend 5
42006: Trend 6
42007: Trend 7
42008: Trend 8
42009: Trend 9
42010: Trend 10
42011: Trend 11
42012: Trend 12
42013: Trend 13
42014: Trend 14
42015: Trend 15
42016: Trend 16
42017: Trend 17
42018: Trend 18
42019: Trend 19
42020: AD0 input
42021: AD1 input
42022: AD2 oil/water continuous input
42023: DA0 output
42024: Water content oil continuous sensor 1
42025: Water content oil continuous sensor 2
42026: Water content water continuous sensor 1
42027: Water content water continuous sensor 1
42028: Water content float
42029: Sensor 1 offset input by user
42030: Sensor 1 offset input by user
42031: Sensor 2 offset input by user
42032: Sensor 2 offset input by user
42033: Storage register for Modbus table index water
value
42034 Storage register for Modbus table sensor 1 value
42035 Storage Register for Modbus table sensor 2 value
42036: Temperature voltage input
42037: Temperature value
42038: Temperature input low voltage
42039: Temperature input low value
42040: Temperature input high voltage
42041: Temperature input high value
42042: Sensor 1 temperature correction
42043: Sensor 2 temperature correction
42044: Water factor 0.00 – 9.99
41023: Modify Table: 0:oil continuous 1:water continuous
41024: Set to 1 to signal table modification ready
42031: Storage register for Modbus table index water
value
42032: Storage register for Modbus table sensor 1 value
42033: Storage register for Modbus table sensor 2 value
