I N S TA L L AT I O N C O N T I N U E D
REMOVING THE OWD SENSOR FROM FLOW THROUGH SPOOLS WITH FIXED INSERTION
®
To remove the OWD sensor, first shut off power to the
®
instrument. Discontinue flow in loop from the main line
FIG. 3-12
and drain fluid from loop. The probe can removed from the
housing by removing screws on collar. Fig. 3-23. The probe
can then be lifted from the cell for testing/inspection/cali-
bration purposes.
Removal should be conducted in accordance with all re-
Hex screws
gional and Class requirements.
