M A I N T E N A N C E C O N T I N U E D
11.
Pushing from the bottom, remove the Antennas. FIG. 5-6
FIG. 5-6
Remove the Antennas from the PEEK Seal Holders by turning them counterclockwise. FIG. 5-7
12.
13.
Slide the Seal Holder Covers off the Antennas. FIG. 5-7 NOTE: The Seal Holder Cover for the stainless
and titanium antennas are different. The cover for the titanium has a larger hole.
14.
Remove the 2-009 and 2-004 O-rings from the Seal Holder. FIG. 5-7
FIG. 5-7
Seal Holder
2-009 O-ring
15.
Clean Sensor Body with parts washer and let it dry.
OWDMANUAL 1114
Seal Holder Cover
2-004 O-ring
31
KAM CONTROLS, INC.
