K A M O W D O P E R AT I O N C O N T I N U E D
OWD PROMPTS
d: Dump Calibrations–displays calibration curves
c: Enter Calibration–this is NOT used to calibrate the OWD and is for factory use only
o: Enter offset–allows users to enter offsets manually. These should be determined by a trained technician or KAM CON-
TROLS representative.
R: 4-20mA Range–sets the 4-20mA range. See page 29 for instructions on how to change the range.
s: Save calibrations/inputs
Z: Displays all sensor values
L: Calibrate–for calibration instructions, see page 28
M: Change Modbus Address: Factory default is "1"
T/u/v/W/i: These are factory settings and should NOT be input by users
CAPTURING HYPERTERMINAL DATA
Hyperterminal data can be captured in multiple ways. Users can simply "select all" and then cut and paste the data
into a word document. Or from the OWD data screen, click on "Transfer." Fig. 4-8. Select "Capture Text" from the drop-
down menu. Select and name and location for the data file, and click "Start." When you are done capturing data, click
on "Transfer" again and select "Stop."
FIG. 4-8
