want to print other characters, then need to set the character
code to 0 or 1;
• Only can print 2 characters on each horizontal dot line.
[Reference]: GS '

4.5.3 ESC '

[Name]：Print curve
[Format]：
[Description]: This command is used to print curve along the
paper feeding direction. N is the curve number need to print,
it should be within the maximum dots of each line.
There are n curve dots within one line. x1， x2......xk indicates
the position of the curve. The number of xk equal to n. Each
xk should be within the maximum dots of each line. CR
means to print this dot line. The whole n curves graphics is
composed by x1，x2......xk and printed by them.
[Notice]: This command is more suitable for such curves
which are detracted within same line. If there are many
continuous line segment within one line, GS' is more
convenient.
[Reference]: GS '
ASCII
Hexadecimal 1B 27 n x1 x2 ...... xk 0D
Decimal
ESC ' n
27 39 n x1 x2 ...... xk 13
40
x1 x2 ...... xk CR
