command is used to print n line segments on one
horizontal line. Using the command continuously can
print out the line segment the user required.
• N is the number of line segment.
• xksL is the LSB for the horizontal coordinate of initial dot
for No. k line segment;
• xksH is the MSB for the horizontal coordinate of initial dot
for No. k line segment;
• xkeL is the LSB for the horizontal coordinate of ending
dot for No. k line segment;
• xkeH is the MSB for the horizontal coordinate of ending
dot for No. k line segment;
• The coordinate is calculated from the left side of print
area, minimum value is 0, maximum is 239, that is, the
maximum value for xkeL+xkeH*25 is 239.
• The data for line segment is no need to arrange in order.
4.5.2 GS "
[Name]：Print characters on the curve
[Format]：
[Description]:
• The printer will print the characters rotated 90 degree from
the current line after receives this command.
• When there has been characters on the horizontal line, if
ASCII
Hexadecimal 1D 22
Decimal
GS " n xL xH c1 c2 ... NULL
n xL xH c1 c2 ... NULL
29 34 n xL xH c1 c2 ... NULL
