Input Parameters - AUTEC LSDCMPPT User Instructions

Image: 3-6 Choose "SysConfig"

3.4 : Input parameters

Method as follows:
1. Before setting parameters please make sure already connected with
controller(Solar Charger/Driver). The remote should be in the range of
the sensor, otherwise it won't set properly. See Image 3-10.
2. Important: Align top of remote with IR receiver sensor on the
controller(Solar Charger/Driver). After LCD shows successful set up of
parameters, press "
the controller(Solar Charger/Driver) is successfully programmed with the
new settings.
Technical Sales / Customer Service:
31328 Via Colinas Suite 102 •
User Instructions for PRLCD Remote
Image: 3-7 Enter "Settings"
Image: 3-9 Setting Successful
", then you will hear a tone, which will indicate
+1-818-338-7788
Westlake Village, CA 91362 USA
6 / 11
