- Page 1 PT Series Multi-Touch Chassis HMI Freescale® Cortex A9 i.MX6 Dual Core, 1GHz (Optional Quad Core) Model No. R15FA3S-PTC3 W15FA3S-PTA3 User Guide Part No. 91521110101V Version 1.1 Please read these instructions carefully before using this product, and save this manual for future use...
-
Page 2: Table Of Contents
PT Series Android HMI User Guide Contents Preface Chapter 1: Introduction 1.1 Features 1.2 Package Contents 1.3 Mechanical Dimensions 1.4 Connector Description 1.5 Physical Buttons and LED Indicators Chapter 2: Installation 2.1 Wiring Requirements 2.2 VESA Mounting 2.3 Turning On 2.4 Connecting Peripherals... - Page 3 Preface 4.5 OS Image Update Guide Appendix Appendix A: Product Specifications Appendix B: Cleaning the LCD Monitor Appendix C: Technical Support...
-
Page 4: Preface
PT Series Android HMI User Guide Preface FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference ... - Page 5 Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.
- Page 6 PT Series Android HMI User Guide Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory.
- Page 7 According to the European Union issued Directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS 2.0). Winmate Inc.’s guaranty is able to meet the current regulations and customer requirements in respect of the application of cadium, lead, mercury,...
-
Page 8: Chapter 1: Introduction
PT Series Android HMI User Guide Chapter 1: Introduction The PT Series HMI runs on low power consuming Freescale® Cortex A9 i.MX6 Dual Core processor. Multiple I/O interface includes USB 2.0 and USB OTG, one LAN port, serial interface RS-232/422/485 and CANBus for machine-to-machine communications, mini USB console port and micro SD card for storage expansion. -
Page 9: Mechanical Dimensions
Chapter 1: Introduction 1.3 Mechanical Dimensions 15-inch, R15FA3S-PTC3 Unit: mm Dimensions:352.50 x 276.70 x 45 15.6-inch, W15FA3S-PTA3 Unit: mm Dimensions:388 x 233 x 40... -
Page 10: Connector Description
Example: A printer to HMI device. 2 Pin Terminal Block – Use to provide DC power to HMI device. 1.5 Physical Buttons and LED Indicators PT Series HMI has Power and Reset physical buttons located on the back side. Item Description Power Button –... -
Page 11: Chapter 2: Installation
Chapter 2: Installation Chapter 2: Installation 2.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. -
Page 12: Vesa Mounting
PT Series Android HMI User Guide 2.2 VESA Mounting This device supports VESA Mounting and provides various types of mounting options to fit any industrial use. Size VESA Plate Screw Size 15” 75x75 mm, 100x100 mm M4 x 5 M4 x 8 15.6”... -
Page 13: Turning On
Chapter 2: Installation 2.3 Turning On Follow the following steps to turn on your device: 1. Connect one side of 2-pin terminal block to DC jack connector to the HMI. Connect the other side to the AC adapter. 2. Connect the power cord to AC adapter. 3. -
Page 14: Connecting Peripherals
PT Series Android HMI User Guide 2.4 Connecting Peripherals 2.4.1 Power Input Connector The DC power source input of the HMI is a 2 pin terminal block connector that supports 12V DC power input. Pin assignment and signal names of power input connector Minimum Voltage 11.4V... -
Page 15: Usb 2.0 Connector
Chapter 2: Installation IMPORTANT: Power Device (PD): follows IEEE 802.3at (25 Watt) 2.4.4 USB 2.0 Connector Use USB A Type (USB 2.0) connector to connect your device to other USB 2.0 compatible devices. Pin assignment and signal names of USB 2.0 connector Pin №... -
Page 16: Speaker
PT Series Android HMI User Guide 2.5 Speaker Speaker is located on the rear side of the display. Electrical Specifications Rated impedance 6±15% ohms@2KHz, 1 Vrms input Power Rating 0.67 W Short Term Max Power 1.3W Acoustical Specifications Sound Pressure Level... -
Page 17: Chapter 3: Operating The Device
Chapter 3: Operating the Device Chapter 3: Operating the Device The PT Series HMI runs on Android 6.0 operating system (Default). 3.1 Home Screen Your device runs on Android 6.0 operating system (Default). Back Opens the previous screen you were working in, even if it was in a different app. -
Page 18: Quick Settings
PT Series Android HMI User Guide Some apps hide these buttons temporarily, or fade them to small dots in the same position. To bring them back, touch the dots, touch the screen in the middle, or swipe up from the bottom. - Page 19 Chapter 3: Operating the Device Open the main Settings menu by touching Settings at the top right.
-
Page 20: Configuring Serial Port Settings
PT Series Android HMI User Guide 3.3 Configuring Serial Port Settings Serial COM Port can be configured for RS-232, RS-422 or RS-485. Winmate provide COM port settings application for Android OS. To configure serial port settings: 1. Settings > Accessibility. - Page 21 Chapter 3: Operating the Device 3. Comport-Setting > Comport 1/ Comport 2/ Comport 3 * Select Comport 1/ Comport 2/ Comport 3 that you want to configure. 4. Comport 1 > RS232/RS422/RS485 * Configure Comport 1 settings...
-
Page 22: Brightness Adjustment
PT Series Android HMI User Guide 3.4 Brightness Adjustment Use can adjust the screen brightness in Android settings. Pull down from the top of the screen to get the notifications area. You can also access display settings in the settings menu. -
Page 23: Ethernet
Chapter 3: Operating the Device 3.5 Ethernet 1. Connect Ethernet Cable to the HMI. 2. Touch All APPS icon, and the open Ethernet application. 3. Ethernet APP main menu appears... -
Page 24: Configuring Ethernet Settings
PT Series Android HMI User Guide 3.5.1 Configuring Ethernet Settings Go to All Apps > Ethernet > Configure Ethernet *Ethernet OFF is set by default. Swipe Ethernet ON to activate Ethernet connection. Connection Type Setting Description DHCP The device automatically capture IP-address from... -
Page 25: Configuring Ethernet
Chapter 3: Operating the Device 3.5.2 Configuring Ethernet To check Ethernet settings: Go to All Apps > Ethernet > Check Ethernet Ethernet settings menu appears on the top right side of the desktop. -
Page 26: Winmate® Home Manager (Whm)
3.6 Winmate® Home Manager (WHM) Winmate® HMI running on Android OS comes with preinstalled APP named Winmate® Home Manager (WHM) which let the device manager to lock the launcher then the user can only use one application assigned by the device manager. - Page 27 Chapter 3: Operating the Device Menu Description Set which app you want to run up automatically Home Manager after booting Password Set the WHM password (Default password is “0000”). Manager About Displays information about Home Manager 2. Go to “Application Selector”, and choose the app which you want to run up automatically after booting.
- Page 28 PT Series Android HMI User Guide 3. Go back to “Home Selector” and press “Clear and Reset Default Home”. 4. Select “Restrict Home” and “Always”, and then restart the computer to enable these settings. The system will automatically start the application which you selected and lock it.
-
Page 29: How To Unlock Applications
Chapter 3: Operating the Device 3.6.2 How to Unlock Applications Follow the instruction below to reset Home Manager. 1. If you want to reset the home manager, pull down the left side to open the status bar and open HomeManager. 2. -
Page 30: How To Change Password
PT Series Android HMI User Guide 3. Restart the system and you will go back to the normal Launcher. 3.6.3 How to Change Password To change the password: 1. Go to Password Manager and set your own password for this APP. -
Page 31: Chapter 4: Software Installation
Chapter 4: Software Installation Chapter 4: Software Installation This chapter contains software installation and updates guide. All the programming guides can be found in the driver CD included in the package. 4.1 Android Debug Bridge Driver Installation IMPORTANT: If your computer is running on Windows Embedded 8 Standard or Windows 8.1 Industry Pro OS system, you need to disable driver signature. -
Page 32: Disabling Driver Signature On Windows 8
PT Series Android HMI User Guide 4.1.1 Disabling Driver Signature on Windows 8 1. Hold down the Windows key on your keyboard and press the letter C to open the Charm menu, and then click the gear icon (Settings). 2. Click Change PC Settings. - Page 33 Chapter 4: Software Installation 3. Click General. 4. Under Advanced Startup, click Restart Now. NOTE: In Windows 8.1, the ‘Restart Now’ button has moved to ‘PC Setting -> Update & Recovery -> Recovery.’ 5. After restarting, click Troubleshoot.
- Page 34 PT Series Android HMI User Guide 6. Click Advanced Options. 7. Click Windows Startup Settings.
- Page 35 Chapter 4: Software Installation 8. Click Restart. 9. After restarting your computer a second time, choose Disable driver signature enforcement from the list by typing the number 7 on your keyboard. Your computer will restart automatically. After restarting, you will be able to install the ADB drivers normally; however, Windows will display a warning message.
-
Page 36: Adb Driver Installation
PT Series Android HMI User Guide Note: The next time you restart your computer, driver signature enforcement will be in effect again. You will have to repeat this process for any new boards. If you have multiple boards to use with the same computer, we recommend installing the drivers for each one before you shut down or restart your computer. - Page 37 Chapter 4: Software Installation 2. In the Update Driver Software window choose Browse my computer for driver software. 3. Select Let me pick from a list of device drivers on my computer. Click Next. 4. Select from your computer 5. In the Update driver software window, click show All Devices and then click Next.
- Page 38 PT Series Android HMI User Guide 6. The system is looking for the driver folder. Click Browse. 7. Select the driver for your OS system. Click Open.
- Page 39 Chapter 4: Software Installation 8. Windows Security window will pop up. This message is used to confirm whether the user wants to install the driver. Select Install this driver software anyway to continue. 9. When the installation is successfully completed you will see Android ADB Interface driver in the Update Driver Software window.
-
Page 40: Installing Android Debug Bridge (Adb)
PT Series Android HMI User Guide 4.2 Installing Android Debug Bridge (ADB) For detailed Android Debug Bridge (ADB) information refer to Android Developers Platform: http://developer.android.com/tools/help/adb.html 1. Decompress adb.zip. Open ADB terminal and move into the adb archive. ADB Terminal window 2. -
Page 41: Downloading Image Tool
Chapter 4: Software Installation 4.3 Downloading Image Tool Download OS Image Tool update guide from Winmate Download Center: 4.4 OTA Update Guide OTA is a tool which can help you to update OS image. To receive Android OS image file contact our sales representatives. Once you get the image file follow the guideline below. - Page 42 PT Series Android HMI User Guide System shows OTA firmware related information. 3. Click Auto-check Update. The system is checking OTA File. It may take some time.
- Page 43 Chapter 4: Software Installation 4. Tap Update Image 5. Make sure the file founded by the system is image update file. Tap OK.
- Page 44 PT Series Android HMI User Guide 6. Make sure the battery level is at least 50%. Tap OK. 7. Tap OK. Important: Do not disconnect the power source! Do not remove the battery!
-
Page 45: Os Image Update Guide
Chapter 4: Software Installation 8. After update the system will automatically restart. 4.5 OS Image Update Guide Download OS Image update guide from Winmate Download Center... -
Page 46: Appendix
PT Series Android HMI User Guide Appendix Appendix A: Product Specifications Model Name R15FA3S-PTC3 W15FA3S-PTA3 Display 15” 15.6” Size Resolution 1024 x 768 1920 x 1080 Brightness Contrast Ratio 700:1 (typ.) 800:1 (typ.) Viewing Angle ~80~80 (H); ~80~80 (V) -85~85(H);-85~85(V) Max Colors 16.2M... -
Page 47: Appendix B: Cleaning The Lcd Monitor
USB OTG Driver Android SDK Linux SDK Guide Download OS Image Tool To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. Also, you can download drivers from Winmate Download Center... - Page 48 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
