PT Series HMI
Intel® Pentium® N4200 Processor (2M Cache, up to 2.5 GHz)
32"
Model No. W32IP3S-PTA3
Quick Start Guide
Document Version 1.0
Document Part No. 91521110106D
Please read these instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate PT Series

Summary of Contents for Winmate PT Series

  • Page 1 PT Series HMI Intel® Pentium® N4200 Processor (2M Cache, up to 2.5 GHz) 32” Model No. W32IP3S-PTA3 Quick Start Guide Document Version 1.0 Document Part No. 91521110106D Please read these instructions carefully before using this product, and save this manual for future use.

  • Page 2: Table Of Contents

    PT Series HMI Quick Start Guide Contents Preface ............................. 3 About This User Manual ......................7 Chapter 1: Introduction ......................8 1.1 Introduction ......................9 1.2 Product Features ....................9 1.3 Package Contents ....................9 1.4 Mechanical Dimensions ..................10 1.5 Physical Buttons ....................

  • Page 3: Preface

    Preface Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.
  • Page 4 PT Series HMI Quick Start Guide Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory.
  • Page 5 Preface be easily accessible. • Keep this equipment away from humidity. • Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. • The openings on the enclosure are for air convection and to protect the equipment from overheating.
  • Page 6 PT Series HMI Quick Start Guide Caution Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Attention Risque d'explosion si la batterie est remplacée par un type incorrect. Jetez les piles usagées conformément aux instructions.

  • Page 7: About This User Manual

    • PT Series HMI User Manual – contains detailed description on how to use the HMI device, its components and features. • PT Series HMI Quick Start Guide - describes how to get the HMI up and running. Note: Some pictures in this guide are samples and can differ from actual product.

  • Page 8: Chapter 1: Introduction

    PT Series HMI Quick Start Guide Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI in the packing list. Mechanical dimensions and drawings included in...

  • Page 9: Introduction

    Giga LAN port, serial interface RS-232/422/485 for machine-to-machine communications, and two USB 3.0 ports for data transfer. Chassis housing is protected with IP65 standard against water and dust from the front side. The PT Series HMI is an ultimate solution for industrial automation and Point-of-Sale (POS) applications.

  • Page 10: Mechanical Dimensions

    USB 3.0 x 2 RJ-45 (LAN) ③ RS232/422/485 1.5 Physical Buttons PT Series HMI has five physical buttons located on the bottom side. Item Description Power – Press to turn on/ off the device. Up - Press to adjust volume/ brightness up.

  • Page 11: Speaker

    0BChapter 1: Introduction 1.6 Speaker Two speakers are located on the rear side of the PT Series HMI. 1.7 Connector Description Terminal interfaces are located on the bottom side of the HMI device. Note: Notice that input and output connectors vary by product size and specifications.

  • Page 12: Chapter 2: Getting Started

    PT Series HMI Quick Start Guide Chapter 2: Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations.

  • Page 13: Connector Description

    TX4+ TX4- 2.1.3 Serial Port Connector The PT Series HMI has one serial port connector to connect your HMI to external devices such as mouse, modem or printer. You can configure serial port settings via jumpers located on the motherboard.

  • Page 14: Usb Connector

    PT Series HMI Quick Start Guide 2.1.4 USB Connector The PT Series HMI device has two USB 3.0 connectors. Use USB 3.0 connector to connect your HMI device to other USB 3.0 compatible devices. Pin assignment and connector description of USB connector.
  • Page 15 1BChapter 2: Getting Started BIOS Setup Utility > Advanced > Serial Port...

  • Page 16: Chapter 3: Mounting

    PT Series HMI Quick Start Guide Chapter 3: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages.

  • Page 17: Wiring Requirements

    100 x 200 mm, 200 x 200 mm Installation Instruction Use Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device. *The picture is for demonstration purposes only. VESA mount accessories are not supplied by Winmate.

  • Page 18: Turning On

    PT Series HMI Quick Start Guide 3.3 Turning On Follow the following steps to turn on your device: 1. Connect one side of the DC jack connector to the 3 pin terminal block of the HMI device. 2. Connect the other side of the DC jack connector to the power cord.

  • Page 19: Chapter 4: Operating The Device

    3BChapter 4: Operating the Device Chapter 4: Operating the Device In this chapter you will find instructions on how to operate the HMI device.

  • Page 20: Introduction

    PT Series HMI Quick Start Guide 4.1 Introduction Your HMI supports Windows 10 IoT Enterprise operating system: • Windows 10 IoT Important: The device is shipped with the OS System according to your order. Contact us if you have any questions regarding OS settings.

  • Page 21: How To Enable Watchdog

    3BChapter 4: Operating the Device 4.3 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information about Watchdog in “Watchdog Guide” that you can download from Winmate Download Center. To enable watchdog in Watchdog AP follow the instructions below: 1.

  • Page 22: Using Recovery Wizard To Restore Computer

    PT Series HMI Quick Start Guide 4.4 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. Important: Before starting the recovery process, remove any expansion card.

  • Page 23: Appendix

    Appendix Appendix Appendix A: Product Specifications Model Name W32IP3S-PTA2 Size/Type 32” TFT Resolution 1920x1080 Brightness 400 nits (typ.) Display Contrast Ratio 4000:1 (typ.) Viewing Angle -89~89(H);-89~89(V) Max Colors 16.7M Touch Projected Capacitive Multi-Touch Intel® Pentium® Processor N4200 Processor (2M Cache, up to 2.5 GHz) 2 GB DDR3L 1866 SO-DIMM System Memory (Optional 8 GB)
  • Page 24 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.

This manual is also suitable for:

W32ip3s-pta3
