PT Series Multi-Touch
Chassis HMI
Intel® Celeron® Bay Trail-M N2930, 1.83 GHz
Model No. R15IB3S-PTC3
W15IB3S-PTA3
User Guide
Part No. 91521110101T
Document Version 1.2
Please read these instructions carefully before using this product, and save this manual for future use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W15IB3S-PTA3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate W15IB3S-PTA3

Summary of Contents for Winmate W15IB3S-PTA3

  • Page 1 PT Series Multi-Touch Chassis HMI Intel® Celeron® Bay Trail-M N2930, 1.83 GHz Model No. R15IB3S-PTC3 W15IB3S-PTA3 User Guide Part No. 91521110101T Document Version 1.2 Please read these instructions carefully before using this product, and save this manual for future use...

  • Page 2: Table Of Contents

    PT Series Windows HMI User Guide Contents Preface Chapter 1: Introduction 1.1 Features 1.2 Package Contents 1.3 Mechanical Dimensions 1.4 Connector Description 1.5 Physical Buttons and LED Indicators Chapter 2: Installation 2.1 Wiring Requirements 2.2 VESA Mounting 2.3 Turning On 2.4 Connecting Peripherals 2.4.1 Power Connector 2.4.2 Ethernet Connector...

  • Page 3: Preface

    Chapter 1: Introduction Preface FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful  interference. This device must accept any interference  received including interference that may cause undesired operation.
  • Page 4 PT Series Windows HMI User Guide Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.
  • Page 5 Chapter 1: Introduction Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory.
  • Page 6 According to the European Union issued Directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS 2.0). Winmate Inc.’s guaranty is able to meet the current regulations and customer requirements in respect of the application of cadium, lead, mercury,...

  • Page 7: Chapter 1: Introduction

    Chapter 1: Introduction Chapter 1: Introduction The PT Series HMI runs on low power consuming Intel® Celeron® N2930 processor. Multiple I/O interface includes USB 2.0, one LAN port, serial interface RS-232/422/485 for machine-to-machine communications, USB 2.0 and USB 3.0 for data transfer. Chassis housing is protected with IP65 standard against water and dust from the front.

  • Page 8: Mechanical Dimensions

    PT Series Windows HMI User Guide 1.3 Mechanical Dimensions 15-inch, R15IB3S-PTC3 Unit: mm Dimensions:352.50 x 276.70 x 45 15.6-inch, W15IB3S-PTC3 Unit: mm Dimensions:388 x 233 x 40...

  • Page 9: Connector Description

    Chapter 1: Introduction 1.4 Connector Description Terminal interfaces are located on the bottom side of the HMI device. Note: Notice that input and output connectors vary by product size and specifications. Terminal interfaces description: Item Description RJ45 – Connects HMI device to Ethernet network. Supports PoE for power transmission in network equipment, via network UTP cable, together with data.

  • Page 10: Chapter 2: Installation

    PT Series Windows HMI User Guide Chapter 2: Installation 2.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: • Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point.

  • Page 11: Vesa Mounting

    75x75 mm, 100x100 mm, 200 x 100 mm Installation Instruction Use Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device. *The picture is for demonstration purposes only. VESA mount accessories are not supplied by Winmate.

  • Page 12: Turning On

    PT Series Windows HMI User Guide 2.3 Turning On Follow the following steps to turn on your device: 1. Connect AC adapter to DC jack connector of the HMI. 2. Connect the power cord to AC adapter. 3. Plug the power cord to the AC outlet. 4.

  • Page 13: Connecting Peripherals

    Chapter 2: Installation 2.4 Connecting Peripherals This section lists HMI connectors and pin assignment. 2.4.1 Power Connector DC power source input is a DC-in power jack connector that accepts 12V DC power input. Pin assignment and signal names of power input connector Pin №...

  • Page 14: Serial Port Connector

    PT Series Windows HMI User Guide 2.4.3 Serial Port Connector Use COM1 serial port connector to connect your HMI to external devices such as mouse, modem or printer. You can configure serial port settings via jumpers located on the motherboard. Pin assignment and signal names of serial port connector Pin №...

  • Page 15: Speaker

    Chapter 2: Installation 2.5 Speaker Speaker is located on the rear side of the HMI. Electrical Specifications Rated impedance 6±15% ohms@2KHz, 1 Vrms input Power Rating 0.67 W Short Term Max Power 1.3W Acoustical Specifications Sound Pressure Level 75±3dB/40cm@1kHz...

  • Page 16: Chapter 3: Operating The Device

    PT Series Windows HMI User Guide Chapter 3: Operating the Device 3.1 Introduction Your HMI supports several versions of Windows OS: • Windows 10 IoT • Windows Embedded 8.1 Industry Pro • Windows Embedded 7 Standard Important: The device is shipped with the OS System according to your order. Contact us if you have any questions regarding OS settings.

  • Page 17: How To Enable Watchdog

    Chapter 3: Operating the Device 3.2 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center. To enable watchdog in Watchdog AP follow the instructions below: 1.

  • Page 18: Using Recovery Wizard To Restore Computer

    PT Series Windows HMI User Guide 3.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: 1.

  • Page 19: Chapter 4: Bios Setup

    Chapter 4: BIOS Setup Chapter 4: BIOS Setup BIOS Setup Utility is a program for configuration basic Input / Output system settings of the computer for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. 4.1 How and When to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, external monitor and press Del key when the prompt appears on the screen during start up.
  • Page 20 PT Series Windows HMI User Guide The following Keys can be used after entering the BIOS Setup. Function General Help Previous Values Optimized Defaults Save & Exit Exit Change Opt. Enter Select or execute command Cursor ↑ Moves to the previous item Cursor ↓...

  • Page 21: Bios Functions

    Chapter 4: BIOS Setup 4.2 BIOS Functions 4.2.1 Main Menu The Main menu displays the basic information about yoursystem including BIOS version, processor RC version, system language, time, and date. When you enter BIOS setup, the first menu that appears on the screen is the main menu.It contains the system information including BIOS version, processor RC version, system language, time, and date.

  • Page 22: Advanced Settings

    PT Series Windows HMI User Guide 4.2.2 Advanced Settings Select the Advanced Tab from the setup menu to enter the advanced BIOS setup screen. You can select any of the items on the left frame of the screen to go to the sub menu for the item, such as CPU Configuration.
  • Page 23 Chapter 4: BIOS Setup 4.2.2.1 Super I/O Configuration Serial Port 1 Configuration Serial Port This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item allows you to select an optimal setting for Super IO device. Options: Auto (Default) / IO=3F8h;...
  • Page 24 PT Series Windows HMI User Guide 4.2.2.2 Hardware Monitor 4.2.2.3 CPU Configuration Active Processor Cores This item sets number of cores to enable in each processor package Options: All (Default) / 1 Limit CPUID Maximum When the computer is booted up, the operating system executes the CPUID instruction to identify the processor and its capabilities.
  • Page 25 Chapter 4: BIOS Setup Options: Disabled (Default) / Enabled Execute-Disable Bit XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3.). Options: Enabled (Default) / Disabled Hardware Prefetcher The processor has a hardware prefetcher that automatically analyzes its...
  • Page 26 PT Series Windows HMI User Guide Package C state limit This item enables or disables package C state limit Options: No Limit (Default) / CO / C1 / C3 / C6 / C7 4.2.2.4 PPM Configuration EIST This item enables or disables Intel SpeedSteps. Options: Enabled (Default) / Disabled CPU C state Report This item enables or disables CPU C state report to OS.
  • Page 27 Chapter 4: BIOS Setup 4.2.2.5 SATA Configuration Serial-ATA (SATA) This item enables/disables Serial ATA Device. Options: Enabled (Default) / Disabled SATA ODD Port This item selects SATA ODD Port Options: No ODD (Default) / Port0 ODD / Port1 ODD SATA Mode This item determines how SATA controller(s) operate.
  • Page 28 PT Series Windows HMI User Guide 4.2.2.6 Network Stack Configuration Network Stack This item enables or disables UEFI network stack Options: Disabled (Default) / Enabled Note: The following items appear only when you set the Network Stack function to [Enabled] IPv4 PXE Support This item enables or disables IPv4 PXE Boot Support.
  • Page 29 Chapter 4: BIOS Setup 4.2.2.7 CSM Configuration CSM Support This item enables or disables CSM Support Options: Disabled (Default) / Enabled Note: The following items appear only when you set the CSM Support to [Enabled] GateA20 Active Upon Request – FA20 can be disabled using BIOS services. Always – do not allow disabling GA20;...
  • Page 30 PT Series Windows HMI User Guide Storage This option controls the execution of UEFI and Legacy Storage OpROM Options: Legacy only (Default) / Do not launch / UEFI only / Legacy first / UEFI first Video This option controls the execution of UEFI and Legacy Video OpROM Options: Legacy only (Default) / Do not launch / UEFI only / Legacy first / UEFI first Other PCI devices...
  • Page 31 Chapter 4: BIOS Setup Legacy USB Support This item determines if the BIOS should provide legacy support for USB devices like the keyboard, mouse, and USB drive. This is a useful feature when using such USB devices with operating systems that do not natively support USB (e.g. Microsoft DOS or Windows NT).

  • Page 32: Chipset Menu

    PT Series Windows HMI User Guide 4.2.3 Chipset Menu This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components.
  • Page 33 Chapter 4: BIOS Setup 4.2.3.1 North Bridge Intel IGD Configuration Integrated Graphics Device Enable: Enable Integrated Graphics Device (IGD) when selected as the Primary Video Apaptor. Disable: Always disable IGD. Options: Enabled (Default) / Disabled IGD Turbo Enable Enable: Enable IGD Turbo Enable. Disable: Enable IGD Turbo Disable. Options: Enabled (Default) / Disabled Primary Display This item selects which of IGD/PCI Graphics device should be Primary...
  • Page 34 PT Series Windows HMI User Guide Options: Enabled (Default) / Disabled LCD Control Boot Display Device This item allows you to select the display device. Options: Auto (Default) Max TOLUD This item sets maxium value of TOLUD. Options: Dynamic (Default) / 1GB / 1.25GB / 1.5GB / 1.75GB / 2GB / 2.25GB / 2.5GB / 2.75GB / 3GB 4.2.3.2 South Bridge Azalia HD Audio...
  • Page 35 Chapter 4: BIOS Setup Options: 11dB (Default) / 14dB / 19dB / 25dB USB Configuration XHCI Mode The item selects Mode of operation of xHCI controller. Options: Smart Auto (Default) / Auto / Enabled / Disabled USB 2.0(EHCI) Support This item controls the USB EHCI (USB 2.0) functions. One EHCI controller must always be enabled.

  • Page 36: Security Menu

    PT Series Windows HMI User Guide 4.2.4 Security Menu This section allows to configure and improve system, and set up some system features according to your preferences. Administrator Password This item sets Administrator Password. User Password This item sets User Password. Secure Boot Secure Boot can be enabled if 1.
  • Page 37 Chapter 4: BIOS Setup Key Management Enroll All Factory Default Keys It allows you to immediately load/clear the default Security Boot keys, Platform key (PK), Key-exchange Key (KEK), Signature database (db), and Revoked Signatures (dbx). The Platform Key (PK) state will change from Unloaded mode to Loaded mode.

  • Page 38: Boot Menu

    PT Series Windows HMI User Guide 4.2.5 Boot Menu Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. Options: 2 (Default) Bootup NumLock State This item selects the keyboard NumLock state. Options: On (Default) / Off Full Screen Logo Display This item allows you to enable/disable Full Screen Logo Show function.

  • Page 39: Exit Menu

    Chapter 4: BIOS Setup 4.2.6 Exit Menu This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. Discard Changes and Exit Abandon all changes made during the current session and exit setup. Save Changes and Reset Reset the system after saving the changes.

  • Page 40: Appendix

    PT Series Windows HMI User Guide Appendix Appendix A: Product Specifications Model Name R15FA3S-PTC3 W15FA3S-PTA3 Display Size 15” 15.6” 300 ����/�� 300 ����/�� Resolution 1024 x 768 1920 x 1080 Brightness Contrast Ratio 2000:1 (typ.) 800:1 (typ.) Viewing Angle ~88~88 (H); ~88~88 (V) -85~85(H);-85~85(V) Max Colors 16.2M...

  • Page 41: Appendix B: Cleaning The Lcd Monitor

    • Don not use water or oil directly on the display screen. If droplets are allowed to drop on the screen, permanent staining or discoloration may occur. Appendix C: Technical Support Winmate provides the following Drivers, SDK and Update Guide: Item Driver Description Utility...
  • Page 42 Notes ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________...
  • Page 43 Notes ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...
  • Page 44 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
