Position the receiver on top of the POWERCUBE with a adhesive pad and feed the receiver antenna leads
down through the side to the frame arms. For further instructions please consult the TBS PowerCube
manual/
Pairing the radio and receiver as covered in your receiver's manufacturer instructions. For further
instructions on installing receivers please consult the TBS PowerCube manual.
Binding using CROSSFIRE receiver
The OBLIVION RTF set comes with the CROSSFIRE Nano receiver already installed, you only need a radio
with CROSSFIRE TX module installed to get started. Note: update CROSSFIRE TX to ​ v 2.24​ or newer firmware
for Nano RX support!
First, install the stubby VTX antenna to avoid overheating the FPVISION board during setup.
Power on the radio and OBLIVION, the CROSSFIRE Nano receiver will enter bind mode automatically since
it was not bound before.
Open the CROSSFIRE configuration menu and select "Binding" mode (On TANGO, go to "Device" then
"CROSSFIRE TX"). The CROSSFIRE TX status LED will turn blue and then green once bound to the receiver.
The receiver might need an update in order to proceed, allow it to update.
Configuration menu on TBS
CROSSFIRE TX module OLED display
Configuration menu on TBS TANGO fpv
remote with TBS CROSSFIRE TX module
