Updating COLIBRI RACE firmware
Getting the latest firmware flashed via TBS Agent is a fast and easy process.
1. Install the latest STM32 VCP drivers:
2. Open TBS Agent and click on the "UPDATE COLIBRI RACE"-tab
3. Press and hold the "BOOT"-button on the COLIBRI board while connecting the micro-USB cable to
the connector next to it to enter DFU programming-mode that allow firmware upgrades
4. Select a firmware from the drop-down menu a nd click "UPDATE" - the process should finish within
15 seconds. These firmwares include tuned settings.
5. Restore OBLIVION factory settings for the particular firmware version in
hitting "Reset Settings" on the first "Setup"-tab. Now, setup flight modes, beeper and LEDs again.
h
ttp://www.st.com/web/en/catalog/tools/PF257938
29
C leanFlight
/
B etaFlight
by
