Team Blacksheep TBS OBLIVION Manual page 3

Specifications
Type:
Frame:
Propellers:
Motors:
Battery:
Power drive:
R/C systems:
FPV camera:
Video transmitter:
VTX antenna:
HD camera:
Flight time:
Range:
Max. altitude:
Working temperature: 0 - 40​
Weight:
Kit contents:
200-size quadrotor FPV racer
Box-shaped, lightweight, strong, composite molded polymer
HQ 5x4.5x3 V3 tri-blade propellers
Custom Cobra CT-2205 2400kV motors
>1300 mAh 4S 14.8V 50C LiPo battery pack, dimensions unrestricted - 1300
to 2200 mAh recommended
TBS POWERCUBE with TBS COLIBRI RACE layer, fastest F3 BetaFlight 3.3
board available, BLHeli-S Multishot TBS POWERCUBE 20A (50A peak) 6S ESC
layers, TBS FPVISION power supply layer
Receiver compatibility with CRSF, PPM, SBUS and SPEK control signal
(COLIBRI UART1)
TBS OBLIVION FPV 650 TVL pilot camera, 2.5mm lens, tilt adjustable 10 to
60° with two different cam mounts
TBS FPVISION 5.8 GHz 24/37-channel user selectable 25/200/500/800mW
Default Band A, CH1 5865 MHz
SMA socket, stubby 5.8GHz omni-directional FPV antenna recommended
GoPro Hero and GoPro Session cinematography mounts included
11 minutes hover time, 2.5 minutes full throttle race time
5 km (requires TBS CROSSFIRE or compatible long range system, included in
RTF)
4000 m ASL
C
° ​
345g weight without battery and HD camera
RTF kit: 1x TBS OBLIVION RTF, 8x HQ 5x4.4x3 propellers, 1x battery skid and
strap, 2x HD camera mounts and strap, 1x Stubby antenna, 1x Propeller
mounting kit, 1x ZeroZero Pilot camera backplate
3
