Replacing parts
The best part of the OBLIVION is that all parts are modular and can be replaced without soldering or
adapting parts. It is all plug & play and can be done in the field or in the car in a snap with a small toolkit.
Replacing canopy
Remove the four screws on the underside of the frame, it is the ones outside the frame arms.
Replacing receiver
Disconnect the control signal cable (RED, BLACK, WHITE/YELLOW) and BST cable (ALL BLACK), untangle the
coax antenna cable from the underside of the frame.
Lift the receiver from the top of the COLIBRI FC, it is kept in place with a double sided adhesive pad.
