Replacing COLIBRI FC
Use the TBS POWERCUBE 5mm hex nut screwdriver (available separately) or use a plier to carefully remove
the four top nuts. Use a plastic spudger to lift the board from all four corners at the same time (avoiding
bending the pin header). Replace with a new COLIBRI board, reprogram it using BetaFlight.
Replacing speed controller
Use the TBS POWERCUBE 5mm hex nut screwdriver (available separately) or use a plier to carefully remove
the four top nuts. Use a plastic spudger to lift the board from all four corners at the same time (avoiding
bending the pin header).
Remove the tape from the arm to release the bullet connectors. Unplug and replace with a new ESC. No
programming needed.
The order of which the ESCs are installed is important. The bottom ESC should connect to the front-left
motor, second last to the back-left motor, third last to the front-right and the top to the back-right.
