Replacing power cable
Remove the entire POWERCUBE stack, either from the bottom four screws or by removing all the boards
from the top. Remove the VTX SMA socket and feed the XT60 connector through the slot in the frame.
Unsolder the power lead and replace with a new one.
Replacing FPV camera
From the underside of the frame, use a ball point hex key to remove the screw holding the camera secure.
Press from the underside of the camera so it snaps free from the support bar.
20
