MICRSafe with 3-Track MSR

CONVERT TO STRING A PROPERTY

Property ID: 27 (0x1B)
Property Type: String
Length: 0 – 7 bytes
Get Property: Yes
Set Property: Yes
Default Value: The default value is no string with a length of zero.
Description: The value is an ASCII string that represents the device's Convert To String
A property. This string can be 0 – 7 bytes long. This string is sent in place of
the character specified in the Convert From Char A property. See the
Convert From Char A property for more information and examples.
This property is stored in non-volatile memory, so it will persist when the unit
is power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled for these changes to take effect.
Example Set Convert To String A property Request (Hex):
Cmd Num
01
Example Set Convert To String A property Response (Hex):
Result Code
00
Example Get Convert To String A property Request (Hex):
Cmd Num
00
Example Get Convert To String A property Response (Hex):
Result Code
00

CONVERT FROM CHAR B PROPERTY

Property ID: 28 (0x1C)
Property Type: Byte
Length: 1 byte
Get Property: Yes
Set Property: Yes
Default Value: 255 (0xFF) (None)
Description: The value is a byte that represents the ASCII value of a character transmitted
by the device as keystroke data that is to be changed into a string of ASCII
values prior to being transmitted by the device as keystroke data. The string
of ASCII values that this value will be changed into is contained in the
Convert To String B property. If the value of this property is set to 0xFF, no
characters will be changed into the string. For example, if you would like a
34
Data Len Prp ID
03 1B
Data Len Data
00
Data Len Prp ID
01 1B
Data Len Prp Value
02 0D 0D
Prp Value
0D 0D
