MICRSafe with 3-Track MSR
The MSR is capable of reading ISO, AAMVA, and CDL encoded cards. The MSR will
autodiscriminate all the card formats when the ID Card Decoding option is enabled using the HW
(Hardware) command (Section 4, Legacy Commands).

LED INDICATORS

Table 3-1 describes the LED indicator conditions for check and card reading operations. The
LED indicator for check reading is located to the left of the slot where the check is first inserted
for reading. The LED indicator for card reading is located on the upper left side of the MSR rail.
LED INDICATOR
OFF
SOLID GREEN
OFF→ SOLID RED
OFF→ SOLID GREEN
FLASH RED/GREEN
FLASH RED
Refer to Appendix C. Troubleshooting Guide.
*
8
Table 3-1. LED indicators
DESCRIPTION
Power off
Ready to read check or card
Check or card read error
Good read
Data sensor blocked (motor does not run)*
Motor sensor blocked (motor does not run)*
