The installation for the MICRSafe is as follows:

REQUIREMENTS

The following is required for the Installation:
•
MICRSafe Device, Part Number 22551001 (VCOM) or 22551002(HID)
•
Standard USB cable, Part Number 22553301
•
Optional auxiliary RS-232 cable, Part Number 22517584
•
DC Power Adapter with Cable, 120VAC to 12 VDC, 1 Amp, Part Number 64300118
(64300121 for international customers)
•
MICRbase software, included in the CD Package Part Number 30037855, or can be
downloaded from: http://www.magtek.com/support/software/demo_programs/ under
MICRbase Setup Program'
'
•
VCOM Driver for MICRSAFE, included in the CD Part Number 30037903 or can be
downloaded from: http://www.magtek.com/support/software/programming_tools/, under
MICRSafe VCOM'
' .

PROCEDURE

Perform the following steps:
1. Connect the interface cable's USB A connector to the PC.
2. Connect the interface cable's USB B connector to the MICRSafe.
3. Connect the DC power adapter's jack to the plug on the MICRSafe.
4. Connect the DC power adapter's plug to the wall outlet.
5. The first time the Reader is connected to the PC, Windows will need to install the USB
driver. See the instructions below.
6. The LED indicator on the MICRSafe should turn on to a steady green. The LED indicator is
located to the left of the slot where the check is first inserted for reading.
Do not place the MICRSafe within 6 inches of a computer
monitor or power supply. These devices may cause undesirable
interference with the check reading operation.

SECTION 2. INSTALLATION

Caution
5
