MICRSafe with 3-Track MSR

ACTIVE KEYMAP PROPERTY

Property ID: 17 (0x11)
Property Type: Byte
Length: 1 byte
Get Property: Yes
Set Property: Yes
Default Value: 0 (United States)
Description: The value is a byte that represents the device's active key map. The value can
be set to 0 for the United States key map or to 1 for the custom key map. The
active key map will be used by the device to convert ASCII data into key
strokes. The United States key map should be used with all hosts that are
configured to use United States keyboards. The custom key map can be used
to set up the device to work with hosts that are configured to use other
countries' keyboards. The default custom key map is the same as the United
States key map. The key map can be modified to another country's key map
by using commands "Get Key Map", "Set Key Map" and "Save Custom Key
Map". See the command section of this manual for a complete description of
these commands. To set up a device to use a custom key map, select the
appropriate key map to be modified using the active key map property, reset
the device to make this change take effect, use the "Get Key Map" and "Set
Key Map" commands to modify the active key map, use the "Save Custom
Key Map" command to save the active key map as the custom key map, set
the active key map property to custom to use the custom key map, reset the
device to make these changes take effect.
This property is stored in non-volatile memory, so it will persist when the unit
is power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled for these changes to take effect.
Example Set Active Keymap property Request (Hex):
Cmd Num
01
Example Set Active Keymap property Response (Hex):
Result Code
00
Example Get Active Keymap property Request (Hex):
Cmd Num
00
Example Get Active Keymap property Response (Hex):
Result Code
00
32
Data Len Prp ID
02 11
Data Len Data
00
Data Len Prp ID
01 11
Data Len Prp Value
01 00
Prp Value
00
