TriMark e-FOB Instructions Manual
E-ask electronic access security keyless-entry, rf keyless-entry system
Hide thumbs
Also See for e-FOB:
- Installation instructions manual (24 pages) ,
- Full-function installation manual (24 pages) ,
- Consumers manual (20 pages)
Subscribe to Our Youtube Channel
Related Manuals for TriMark e-FOB
Summary of Contents for TriMark e-FOB
- Page 1 Electronic Access Security Keyless-entry e-FOB RF Keyless-entry System Instructions FCC ID: TV2EFOB1...
-
Page 2: Table Of Contents
Panic Mode ...................6 Vehicle Alarm..................7 Horn/Siren Chirp ...................7 Starter Kill Feature ................7 Troubleshooting ..................8 Appendix: Installation and Mounting e-FOB System ......I General Mounting Guidelines: ...............I Wiring color code tables and diagrams..........I RF RECEIVER ......................I Wiring Connections for Basic System Functions........ IV... -
Page 3: Introduction
Introduction e-FOB Operation and Features This manual provides the necessary information for the installation and use of TriMark’s e-FOB transmitter/receiver system. Basic functions of the system include: Lock button • Locking and unlocking entry doors Horn button • Light activation •... -
Page 4: Teaching Additional Fob Transmitters
Teaching Additional Fob Transmitters Smart Led: The smart LED indicates system status: • Slow Flash = Armed • Off = Disarmed • Fast Flash = Alarm activated Dip Switch Setting Assignment The DIP Switch settings control additional functions. Power to the receiver should be disconnected and reconnected after a DIP switch is changed. -
Page 5: Dip Switch #1: Horn/Panic Mode
DIP Switch #1: Horn/Panic Mode DIP Switch #7: Automatic Lock/Unlock • • DIP switch #1 ON: the Horn button (center left) provides a pulse DIP switch #3 ON: the auto-locking feature is activated. All doors output. are locked 5-seconds after ignition start. Doors unlock when the •... -
Page 7: Appendix: Installation And Mounting E-Fob System
Lock Input (-) The following tables and diagrams are provided to show color-coded wire Blue/White Unlock Input (-) and pin assignments for the e-FOB system. Connect all wires before WIRE COLORS CONNECTOR 4: 14-PIN HARNESS plugging module into wiring harness. -
Page 8: Wiring Connections For Basic System Functions
Wiring Connections for Basic System Functions WIRE COLORS CONNECTOR 5: 10-PIN HARNESS Green/Black Door Lock (N/C) (relay 30A) Purple Dome Light Output (relay 15A) Pink Dome Light (N/O) (relay 15A) Pink/Black Dome Light (N/C) (relay 15A) Green/White Door Lock (N/O) (relay 30A) Green Lock Output (relay 30A) Blue/Black...
