TriMark e-FOB Consumers Manual

Electronic access security keyless-entry rf keyless rf keyless-entry
Hide thumbs Also See for e-FOB:
Table of Contents

Advertisement

Quick Links

Download this manual
e-ASK
A
S
K
e
lectronic
ccess
ecurity
eyless-entry
e
-
FOB
RF Keyless
-
entry
e
-
FOB
RF Keyless
-
entry
Full Function Consumer Manual
Full Function Consumer Manual
FCC ID: TV2EFOB1
FCC ID: TV2EFOB1
(UM19 ~ 22793-01)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the e-FOB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TriMark e-FOB

Summary of Contents for TriMark e-FOB

  • Page 1 e-ASK lectronic ccess ecurity eyless-entry RF Keyless entry RF Keyless entry Full Function Consumer Manual Full Function Consumer Manual FCC ID: TV2EFOB1 FCC ID: TV2EFOB1 (UM19 ~ 22793-01)

  • Page 2: Table Of Contents

    Table of Contents Introduction .................. 1 e-FOB Operation and Features - Standard Mode ...... 2 e-FOB Operation and Features - Cargo Mode ......2 Teaching Additional FOB Transmitters ........3 Training Wireless Switches ............. 4 Additional System Features ............5 Light Activation ................

  • Page 3: Introduction

    Introduction This manual provides the necessary information for the proper use of TriMark’s e-FOB transmitter/receiver system. Basic functions of the system include:  Locking and unlocking entry and compartment doors  Light activation  Panic mode (standard configuration only)  Auxiliary function support The e-FOB system includes: ...

  • Page 4: E-Fob Operation And Features-Standard Mode

    Cargo Lock Locks cargo compartments and arms security system. Unlocks compartment doors and disarms security Cargo Unlock system. Notes:  While the engine is running only the Unlock (Entry Unlock) function of the e-FOB remains activated — other functions are deactivated.

  • Page 5: Teaching Additional Fob Transmitters

    Teaching Additional FOB Transmitters 1. Plug the LED into C6 and the push button into C7 on the receiver. Your OEM may have already installed these in your vehicle. 2. Turn ignition off and disarm alarm. 3. Press and release the programming button 3 times. The LED will turn on red after 3 seconds.

  • Page 6: Training Wireless Switches

    Training Wireless Switches Up to 20 wireless switches can be trained to the RF controller. A wire- less switch can provide door ajar information, input from a shock sen- sor, a motion sensor, a glass break sensor, etc. 1. Plug the LED into C6 and the programming button into C7 on the receiver.

  • Page 7: Additional System Features

    Additional System Features Light Activation When the alarm is armed, the parking lights and headlights flash. With an unlock instruction from the key fob, the dome light stays illuminated for 30 seconds and the parking and headlights flash. 2nd Unlock Output Press and release the Unlock button twice to unlock the bay doors.

  • Page 8: Emergency Override

    Emergency Override To disarm the alarm in case of FOB transmitter loss or malfunction: 1. Turn ignition on. 2. Press and hold the push button for 3-seconds. LED turns off. 3. Turn ignition off. Starter Kill Feature The starter kill feature is active for 30 minutes after the alarm is activated.

  • Page 9: Troubleshooting

    Remote transmitter FOBs, batteries, and other equipment subject to normal wear and deterioration may need to be replaced periodically by dealer and/or end user and are not covered by this warranty. TriMark will not be liable for indirect, special, incidental or consequential damages.
  • Page 12 UM19 22793-01 09/13-4...
