TriMark e-Ask e-FOB System Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
e-ASK
A
S
K
e
lectronic
ccess
ecurity
eyless-entry
e
-
FOB
RF Keyless
-
entry
e
-
FOB
RF Keyless
-
entry
System Instructions
System Instructions
(UM02 ~ 19571-02)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the e-Ask e-FOB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TriMark e-Ask e-FOB

Summary of Contents for TriMark e-Ask e-FOB

  • Page 1 e-ASK lectronic ccess ecurity eyless-entry RF Keyless entry RF Keyless entry System Instructions System Instructions (UM02 ~ 19571-02)

  • Page 2: Table Of Contents

    Table of Contents Introduction .................. 1 e-FOB Operation and Features ........... 2 Teaching Additional Fob Transmitters ........3 Smart Led .................. 4 Dip Switch Setting Assignment ..........4 DIP Switch #1: Sustained Output ..........4 DIP Switch #2: Horn/Panic Mode ..........4 DIP Switch #3: Automatic Lock/Unlock ........

  • Page 3: Introduction

    Introduction This manual provides the necessary information for the installation and use of TriMark’s e-FOB transmitter/receiver system. Basic functions of the system include:  Locking and unlocking doors  Light activation  Panic mode  Auxiliary functions based upon configuration (see page 4) The e-FOB system includes: ...

  • Page 4: E-Fob Operation And Features

    e-FOB Operation and Features Lock button Unlock button * button Horn button Button Function Lock Locks all entry doors and arms security system. Unlocks entry doors and disarms security system. Unlock Also activates the porch light. Activates panic mode when pressed and held for 2 Horn seconds.

  • Page 5: Teaching Additional Fob Transmitters

    Teaching Additional FOB Transmitters 1. Plug the smart LED into CN4 and the push button into CN5. 2. Apply +12 V to the yellow wire. 3. Press and hold the push button switch until the LED assembly turns on and then off (about 5 seconds). 4.

  • Page 6: Smart Led

    Smart LED: The smart LED indicates system status:  Slow flash = Armed  Off = Disarmed  Solid on = Valet mode  Fast flash = Alarm activated since last Unlock button press DIP Switch Setting Assignment The DIP Switch settings control additional functions. A DIP switch change is recognized after the Lock button is pressed.

  • Page 7: Dip Switch #3: Automatic Lock/Unlock

    DIP Switch #3: Automatic Lock/Unlock  DIP switch #3 ON: the auto-locking feature is activated. All doors are locked 5-seconds after engine start. Doors unlock when the engine is turned off. THIS FEATURE IS CANCELED AUTOMATICALLY if the door is open or opened when the engine is started.

  • Page 8: Vehicle Alarm

    Vehicle Alarm (when installed) The alarm is armed when the doors are locked. If any outside door is opened while the alarm is set, the horn, siren, and lights flash for 1 minute. Press the Unlock button to deactivate the alarm. Valet Mode (requires hook-up to ignition) Some situations, such as valet parking, or leaving the vehicle at the dealer, require that alarm features be suspended.

  • Page 9: Starter Kill Feature

    Starter Kill Feature Wire the starter through CN2 and CN3. Once installed this feature defeats the starter if the alarm is set off so that the vehicle cannot be stolen. DO NOT BYPASS THE IGNITION OR FUEL PUMP. In case of an emergency, the starter kill feature can be bypassed with the emergency override.

  • Page 10: Troubleshooting

    Remote transmitter FOBs, batteries, and other equipment subject to normal wear and deterioration may need to be replaced periodically by dealer and/or end user and are not covered by this warranty. TriMark will not be liable for indirect, special, incidental or consequential dam-...

  • Page 11: Appendix: Installation And Mounting E-Fob System

    Appendix: Installation and Mounting e-FOB System Contact TriMark for specific mounting details, such as drawings, placement suggestions, mounting hardware, etc. General Mounting Guidelines: The RF receiver should be placed in an interior location that does not shield RF signals. You may need to try multiple locations to optimize reception.
  • Page 12 WIRE COLORS 14-PIN HARNESS AUX. Button INPUT/OUTPUT. PURPLE / WHITE BUILT-IN RELAY, 12A. PURPLE / WHITE A FUSE IS RECOMMENDED WHITE / GREEN LOCK OUTPUT (N/C RELAY 30) WHITE / BLACK LOCK INPUT (N/C RELAY 87A) YELLOW CONNECT TO TRUE IGNITION CONNECT TO A CLEAN GROUND.
  • Page 13 WIRE COLORS 10-PIN HARNESS ORANGE ARMED OUTPUT (-) 500MA. AUX. CHANNEL #2 FOR LONG WHITE / BROWN UNLOCK BUTTON PRESS OUTPUT, (-) 500MA BROWN / WHITE HORN HONK OUTPUT, (-) 500MA WHITE / YELLOW 2ND UNLOCK (-) 500MA. GRAY LIGHTS OUTPUT. (-) 500MA PURPLE / GREEN UNASSIGNED INPUT WHITE / BLUE...

  • Page 14: Wiring Connections For Basic System Functions

    Wiring Connections for Basic System Functions...
  • Page 15 Notes...
  • Page 16 UM02 19571-02 01/06-8...
