  • Page 1 e-ASK Electronic Access Security Keyless-entry e-ASK Keyless-entry System Installation & Instructions June 2008...
  • Page 2: Table Of Contents

    Table of Contents Introduction .....................3 Cargo e-FOB Operation and Features ..........3 Non-doorbell e-PAD Operation and Features ........4 Locking doors with keypad ..............4 Secure Operations................4 e-ASK CAN DIP Switch Configuration –..........5 Additional Features.................5 Dome/Porch Light Activation ..............5 e-PAD Anti-tamper Deactivating Feature ..........5 Trim Pot Variable Resistor........錯誤! 尚未定義書籤。...
  • Page 3: Introduction

    Introduction This manual provides the necessary information for the proper installation and use of TriMark’s CAN e-ASK system. The e-ASK system comes with the following components: • e-FOB (keyless entry radio frequency [RF] FOB transmitter and receiver) • e-PAD keypad user interface...
  • Page 4: Non-Doorbell E-Pad Operation And Features

    Non-doorbell e-PAD Operation and Features The e-PAD is shipped with default authority and access codes. Unless the OEM or dealer has changed default codes, the authority and access codes are as follows: Access code: Digit 1 Digit 2 Digit 3...
  • Page 5: E-Ask Can Dip Switch Configuration

    e-ASK CAN DIP Switch Configuration – • DIP switches 1-3: The settings of DIP switches 1-3 define CAN address of the IO RF receiver module. The setting a unique address is required if multiple modules are used on CAN network. If only 1 module is used on network then all DIP switches should be set to default ON position.
  • Page 6: Keypad Learn Wire

    (zone 1). The compartment doors are locked and unlocked with a single pulse. The locking and unlocking pulses have opposite polarities. Locking and unlocking operations are activated via vehicle switch inputs or according to e-PAD and e-FOB instructions.
  • Page 7: Teaching Additional Transmitter Fobs

    Teaching Additional Transmitter Fobs There are 2 ways that one can put the receiver into learn mode. The first requires that a CAN keypad be connected to the network. This option allows the receiver to be put into train mode without accessing the module. The 2 option requires one to have access to the receiver, but a keypad is not required.
  • Page 8 13. Reconnect CAN connector. 14. Reconnect power to door module. 15. Verify that fobs are synched to the door module and that range is of RF transmission is acceptable. Door module needs to be connected to a valid CAN network (2+ modules on network) for verify functionality.
  • Page 9: Teaching Keypad New Authority / Access Codes

    Teaching Keypad New Authority / Access Codes When you assign a new authority code, you delete the existing authority code as well as any access codes. Note: The authority code you assign following these instructions also becomes an access code saved to the 1/2 button. 1.
  • Page 10: Assign New Access Codes

    Assign New Access Codes With a valid authority code (see pages 4 and 9), an access code can be programmed with the following instructions. 1. Press the (5/6) button for 5 seconds, the keypad will beep. The backlighting LED of the keypad will flash indicating the learn mode.
  • Page 11: Wiring Assignments

    Wiring Assignments Deutsch Enclosure Style Gray Left Header Antennae pin (solid Courtesty Dome core wire Light Output recommended) 3 CAN Low 4 Entry lock output 5 CAN High 6 Ground Entry Window Down Input Entry unlock input unlock Entry lock input (5) 11 Window UP input (1) output 7 Power...
  • Page 12 Gray Left Header Courtesty Dome Light Output Remote Fob Transmitter Antennae pin (solid core wire recommended) CAN Low Entry lock output CAN High Ground Power Entry unlock output Entry unlock input Window Down Input Window UP input Entry lock input (5) Black Right Header Ground Door ajar input...
  • Page 13: Troubleshooting

    One particular e-FOB function function at RF module, wiring harness, does not work. and I/O module. e-PAD Hints Verify power to the I/O module. Verify that keypad cable is connected. No response with button press (rest of system will function) Verify that code has not been changed.
  • Page 14 e-ASK I/O Module Hints No response in any system Verify power to the I/O module. element. No LED flash (LED is under enclosure cover). Verify DIP switches are set to correct Unexpected operations occurs configuration setting. I/O module is detecting problem with communication network (CAN).
  • Page 15 FCC ID: TV2EFOBII FCC Compliance and Advisory Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
