TriMark e-FOB Consumers Manual

Electronic access security keyless-entry
Hide thumbs Also See for e-FOB:
Table of Contents

Advertisement

Quick Links

See also: Manual
e-ASK
A
S
K
e
lectronic
ccess
ecurity
eyless-entry
e
-
FOB
/ e
-
PAD
e
-
FOB
/ e
-
PAD
Consumer Manual
Consumer Manual
FCC ID: TV2EFOB1
FCC ID: TV2EFOB1
(UM12 ~ 22271-02)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the e-FOB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TriMark e-FOB

Summary of Contents for TriMark e-FOB

  • Page 1 e-ASK lectronic ccess ecurity eyless-entry Consumer Manual Consumer Manual FCC ID: TV2EFOB1 FCC ID: TV2EFOB1 (UM12 ~ 22271-02)

  • Page 2: Table Of Contents

    Table of Contents Introduction .................. 1 e-FOB Operation and Features - Standard Mode ...... 2 e-FOB Operation and Features - Cargo Mode ......3 Standard e-PAD Operation and Features ........4 Lock Doors with Keypad ............4 Using Secure Operations ............4 Available Secure Operations .............
  • Page 3 Additional System Features ............12 Light Activation ................12 2nd Unlock Output ..............12 3rd Unlock Output ..............12 2nd Auxiliary Output ..............12 Panic Mode ................12 Lock/Unlock Confirmation ............12 Lock/Unlock Confirmation Control ..........12 Emergency Override ..............13 Starter Kill Feature ..............

  • Page 4: Introduction

    Clean acrylic rod with mild soap and water only. The Full-Feature RF receiver and FOB transmitters are shipped programmed. After making all necessary wiring connections the e-PAD / e-FOB system will function as indicated in this manual. TriMark Full-Feature e-GRAB Handle RF Controller...

  • Page 5: E-Fob Operation And Features - Standard Mode

    Operation and Features - Standard Mode Lock button Horn button button Unlock button Button Function Lock Locks all doors and arms security system. Unlocks doors and disarms security system. Also Unlock activates the dome light. Activates panic mode when pressed and held for Horn 2 seconds.

  • Page 6: E-Fob Operation And Features - Cargo Mode

    Operation and Features - Cargo Mode Entry Lock Cargo Lock Cargo Unlock Entry Unlock Button Function Locks entry doors and arms security system. Entry Lock Unlocks entry doors and disarms security system. Also Entry Unlock activates the porch light.

  • Page 7: Standard E-Pad Operation And Features

    Standard e-PAD Operation and Features The e-PAD is shipped with default Authority and Access Codes. Unless the OEM or dealer has changed default codes, the Authority and Access Codes are: Access code: Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 1 / 2 3 / 4...

  • Page 8: Doorbell E-Pad Operation And Features

    Doorbell e-PAD Operation and Features Access code: Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Authority code: Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Lock Doors With Keypad Press and hold down the (1) button for 1-2 seconds. An access code is not needed to lock the doors.

  • Page 9: More E-Pad Features

    More e-PAD Features Protective Deactivating Security Feature If a correct code is not entered after 20 button presses, the keypad enters an inactive mode that disables button recognition for 1 minute. This helps prevent unauthorized access by entering random codes. There is no button feedback while the system is disabled.

  • Page 10: Teaching Additional Fob Transmitters

    Teaching Additional FOB Transmitters 1. Plug the LED into C6 and the push button into C7 on the receiver. These may already be plugged into your module by the OEM. 2. Turn ignition off and disarm alarm. 3. Press and release the programming button 3 times. The LED will turn on red after 3 seconds.

  • Page 11: Training Wireless Switches

    Training Wireless Switches Up to 20 wireless switches can be trained to the RF controller. A wireless switch can provide door ajar information, input from a shock sensor, a mo- tion sensor, a glass break sensor, etc. 1. Plug the LED into C6 and the programming button into C7 on the receiver.

  • Page 12: Teaching Keypad New Authority / Access Codes

    Option 1. Use when you cannot find the RF controller or if the OEM does not fully install the e-PAD / e-FOB system. Preparation: 1. Find the wiring harness coming out of the back of the keypad. This is usually behind the passenger armrest next to the entrance door.

  • Page 13: Option 2

    Option 2. Use when you have access to the RF controller and you are certain the OEM has fully hooked up e-PAD / e-FOB system (not common). Preparation: 1. Plug the LED into C6 and the push button into C7 on the receiver (see page 6).

  • Page 14: Assign New Access Codes

    Assign New Access Codes The Access Codes are used for secure functions, such as unlocking doors. The Access Codes must be EXACTLY 5 digits long. With a valid Authority Code, an Access Code can be programmed with the following instructions: 1.

  • Page 15: Additional System Features

    Additional System Features Light Activation When the alarm is armed, the parking lights and headlights flash. With an unlock instruction from either the fob transmitter or keypad; the dome light stays illuminated for 30 seconds and the parking and headlights flash. 2nd Unlock Output Press and release the Unlock button on the fob transmitter twice for a pulse output.

  • Page 16: Emergency Override

    Emergency Override To disarm the alarm in case of FOB transmitter and access code loss: 1. Turn ignition on (apply 12V to yellow wire). 2. Press and hold the push button for 3-seconds. LED turns off. 3. Turn ignition off (remove 12V from yellow wire). Starter Kill Feature The starter kill feature is active for 30 minutes after the alarm is activated.

  • Page 17: Troubleshooting

    Check FOB transmitter battery voltage. operation Batteries need to be changed every 1-2 years depending on usage. Check wire connection of affected One particular e-FOB function function at RF module and wiring does not work harness e-PAD Hints No response with button press Verify connection of keypad.
  • Page 18 Remote transmitter FOBs, batteries, and other equipment subject to normal wear and deterioration may need to be replaced periodically by dealer and/or end user and are not covered by this warranty. TriMark will not be liable for indirect, special, incidental or consequential damages.
  • Page 20 UM12 22271-02 09/13-7...
