Repair Instructions
™
XD40
Hose Reels Repair
Instructions for repairing hose reels used in applications requiring long range dispense,
transfer or evacuation of motor oils, diesel fuels*, lubricants, water, waste oil and air.
Not for use with gasoline or other flammable fluids. Not approved for use in hazardous or
explosive atmosphere locations. For professional use only.
*less than 20% biofuel content
Models
(see page 3 for addition model information)
Spring Hose Reels
XD40 - Floor, Truck-bed or Overhead Mounted
XD50 - Floor or Truck-bed Mounted
XD40
and XD50
™
Important Safety Instructions
Read all warnings and instructions in this
manual and the XD40 and XD50 Operation
Manual. Save these instructions.
Related Manual:
3A2990 - Installation and Operating Instructions
XD50
332203F
EN
