Instructions – Parts List
Parts
Series 700 Hose Reels
1500 psi (10 MPa, 102 bar) Maximum Working Pressure
Fuel hose only: 125 psi (0.87 MPa, 8.7 bar) Maximum Working Pressure
Read warnings and instructions.
See page 3 for List of Models.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
Copyright 1995, Graco Inc. is registered to I.S. EN ISO 9001
Model 241910 shown
308546M
05265
Advertisement
Table of Contents
Related Manuals for Graco 700 Series
Summary of Contents for Graco 700 Series
- Page 1 Fuel hose only: 125 psi (0.87 MPa, 8.7 bar) Maximum Working Pressure Read warnings and instructions. See page 3 for List of Models. Model 241910 shown 05265 GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441 Copyright 1995, Graco Inc. is registered to I.S. EN ISO 9001...
-
Page 2: Table Of Contents
....... Maintenance Graco Standard Warranty .... - Page 3 List of Models The models listed here include the medium-pressure—1500 psi (10 MPa, 102 bar)—Series 700 hose reel. The hoses in these models, except for Models 241910, 241909, and 237884, have a pressure rating of at least 1500 psi. Model Hose Stop Kit Hose Part No.
-
Page 4: Warnings
D Read all instruction manuals, tags, and labels before operating the equipment. D Use the equipment only for its intended purpose. If you are not sure, call your Graco distributor. D Do not alter or modify this equipment. Use only genuine Graco parts and accessories. Modifying parts can cause a malfunction and result in serious bodily injury. - Page 5 WARNING INJECTION HAZARD Fluid from the dispensing valve, leaks, or ruptured components can inject fluid into your body and cause extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the skin can also cause serious injury. D Fluid injected into the skin might look like just a cut, but it is a serious injury.
- Page 6 WARNING FIRE AND EXPLOSION HAZARD Improper grounding, poor ventilation, open flames, or sparks can cause a hazardous condition and result in a fire or explosion and serious injury. D Be sure the entire fluid system is properly grounded. The hoses supplied with these hose reels are electrically conductive.
-
Page 7: Installation Typical Layout
The installation shown in Fig.1 is only a guide for selecting and installing a hose reel system. The components and accessories shown are the minimum requirements for all systems; however, it is not an actual system design. Contact your Graco distributor for assistance in designing a system to suit your needs. Main air supply line... -
Page 8: Accessories And Restrictions
Installation–Accessories and Restrictions NOTE: The air and fluid accessories for your pump Fluid Line Accessories must be properly sized to that pump. Refer to your Install the following fluid line accessories in the order specific pump manual for selecting pump accessories. shown in Fig. -
Page 9: Roller Support Arm
Installation–Roller Support Arm Series 700 hose reels are shipped with the hose 3. Remove the roller plate from the hose reel base rollers bolted near the reel mounting base, which is the (14), and install the roller support arms (49). proper position for truck-mounted hose reels. -
Page 10: Mounting Options
Installation–Mounting Options All Mountings NOTE: Always use large flat washers with the bolts 2. If you are installing permanent supply lines, drill you use to mount the hose reel pedestal to any 1.5 in. (38 mm) diameter holes through the ceiling surface. -
Page 11: Overhead Mounting To An I-Beam
Installation–Mounting Options Overhead Mounting to an I-Beam NOTE: You should have the hose installed on the reel 3. Connect the supply line to the inlet of the reel. before you mount the reel overhead. See Installing a Hose on page 12 if you do not already have the hose installed on the reel. -
Page 12: Installing A Hose
Installation–Hose To install a hose on a hose reel with the proper amount 4. Attach a C-clamp to the reel flange, as shown in of spring tension, follow these steps: Fig. 5, to help prevent the reel from unintentionally becoming unlatched and spinning freely. WARNING WARNING Never allow the reel to spin freely. -
Page 13: Adjusting Spring Tension
Installation–Adjusting Spring Tension If the hose cannot be pulled out all the way, or if it does 4. Rotate the reel in the direction of the appropriate not retract all the way back onto the hose reel, you arrow shown in Fig. 6, keeping the hose wrapped need to adjust the spring tension. -
Page 14: Maintenance
Maintenance Pressure Relief Procedure Replacing the Service Hose WARNING WARNING To reduce the risk of serious injury whenever you INJECTION HAZARD are instructed to relieve pressure, always follow the The system pressure must be manually Pressure Relief Procedure at left. relieved to prevent the system from dis- pensing accidentally. -
Page 15: Oiling The Hose Rollers
Maintenance 7. Attach the other end of the new hose to the Oiling the Hose Rollers 90-degree elbow. Every six months, apply one or two drops of light 8. Remove the C-clamp from the reel flange. motor oil to lubricate the hose reel at point A. See Fig. -
Page 16: Swivel
Service Swivel WARNING 3. Remove the o-rings (36), backup rings (37), and quad rings (38), and clean and inspect them for To reduce the risk of serious injury whenever you wear or damage. are instructed to relieve pressure, always follow the Pressure Relief Procedure on page 14. -
Page 17: Spring Canister
Service Spring Canister To replace the spring canister, follow the steps below. Do not attempt to service the spring inside of the spring canister. Read the warning below regarding the spring hazard. WARNING HOSE REEL SPRING HAZARD The only service you should perform on the reel spring is replacing the spring cannister. -
Page 18: Parts List
Parts List Model 237728, Series B Bare Hose Reel Part No. Description Part No. Description 237697 SPOOL, hose 190377 TUBE, roller, 7.05 in. 190373 SHAFT, spring cannister 190363 PIN, roller 113267 KEY, square 190729 PLATE, roller 113051 SEAL, dust 102005 PIN, spring 5 Y{ 290070 LABEL, warning... -
Page 19: Parts Drawing
Parts Drawing Model 237728, Series B Bare Hose Reel Apply lubricant to all bearing and sealing surfaces. Use washers for .030-in. (0.76 mm) maximum space between back of bearing and retaining washer. Torque to 25 to 35 ft-lb (33.9 to 47.5 N.m). Bearings must be positioned with the 1/4-in. -
Page 20: Identification Labels
Accessories Must be purchased separately. Use only Roller Support Kit 237944 genuine Graco parts and accessories. Positions the roller plate for overhead installations and enables the hose to hang straight down through the Identification Labels 180698 hose rollers. Sheet of 14 sticky-back labels for labeling hose reels. -
Page 21: Technical Data
Technical Data Maximum working pressure ........... . 1500 psi (10 MPa, 102 bar) Inlet size . -
Page 22: Dimensions
Dimensions 10.45 in. (265 mm) mounting holes, center to center 05278 22.25 in. (565 mm) mounting holes, center to center 11.83 in. (300 mm) base width 24.00 in. (609 mm) base length 26.25 in. (667 mm) total height 25.00 in. (635 mm) reel diameter G 13.60 in. - Page 23 Notes 308546...
-
Page 24: Graco Standard Warranty
Graco distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
