Graco 350 Series Instructions-Parts List Manual

Hide thumbs Also See for 350 Series:

Instructions-parts list manual (28 pages)

Instructions and parts list (26 pages)

page of 24

/ 24
Bookmarks

Quick Links

Download this manual

Instructions–Parts List

Series 350 Hose Reels

Used to dispense lubrication products, air, water, transmission fluid and antifreeze.

NOTE: These hose reels are for stationary mountings only and cannot be used with enclosures.

Important Safety Instructions.

Read all warnings and instructions in this manual.

Save these instructions.

See page 2 for List of Models and Table of

Contents.

WARNING

These hose reels are designed to dispense lube

products, air, water, transmission fluid, or anti-

freeze only. Any other use of these hose reels can

cause unsafe operating conditions and result in

component rupture, fire, or explosion, which could

cause serious bodily injury, including fluid injection.

308400ZAA

ENG

03711C

Need help?

Do you have a question about the 350 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Graco 350 Series

Page 1 Instructions–Parts List 308400ZAA Series 350 Hose Reels Used to dispense lubrication products, air, water, transmission fluid and antifreeze. NOTE: These hose reels are for stationary mountings only and cannot be used with enclosures. Important Safety Instructions. Read all warnings and instructions in this manual. Save these instructions.
Page 2 ........Graco Standard Warranty ..... .
Page 3 Symbols Warning Symbol Caution Symbol WARNING CAUTION This symbol alerts you to the possibility of serious This symbol alerts you to the possibility of damage to injury or death if you do not follow the instructions. or destruction of equipment if you do not follow the instructions.
Page 4 D Read all instruction manuals, tags, and labels before operating the equipment. D Use the equipment only for its intended purpose. If you are not sure, call your Graco distributor. D Do not alter or modify this equipment. Use only genuine Graco parts and accessories. Use only extensions that are designed for use with your dispensing valve.
Page 5 Installation – Typical Installation Overhead-Mounted Hose Reel NOTE: Parts are not proportional. 03791 Main air supply line Fluid drain valve (required) Pump air supply line Fluid shutoff valve Air filter Fluid line Air regulator Hose reel fluid inlet kit Bleed-type master air valve (required) M Hose reel Pump Dispensing valve...
Page 6 However, it is not an Fig. 1, using adapters as necessary: actual system design. Contact your Graco distributor for assistance in designing a system to suit your D Fluid Drain Valve (H): install the drain valve point- particular needs.
Page 7 Installation – Mounting Options All Mountings 5’ (1.5 m) for motor oil NOTE: Always use large flat washers with the bolts 6’ (1.9 m) minimum you use to mount the hose reel pedestal to any for 1 lift surface. Center between two lifts CAUTION Be sure the mounting surface is strong enough to...
Page 8 Installation – Mounting Options Ceiling Mounting Without an I-Beam 2. Determine the desired position of the roller support arm (37) 1. Install the mounting frame (303) and base plate D The hose reel is factory-assembled and shipped (304) as shown in Fig. 3. with the roller support arm (37) in position AA.
Page 9 Installation – Mounting Options Ceiling Mounting Directly to an I-Beam NOTE: The reel base is slotted (A) to allow two screws to be started before mounting the reel to the support. See Fig. 3. 1. Using the template (B) provided, drill holes in the I-Beam (C).
Page 10 Installation – Installing a Hose Installing a Hose on a Bare Reel NOTE: The reel base (303) has two holes (H). Run the inlet hose through either hole, depending on the 1. Locate the length and size of your hose in the orientation of the hose reel.
Page 11 Installation – Increasing Spring Tension Increasing Spring Tension NOTE: Do not put so many loops onto the reel that the spring winds up tightly before the hose is fully 1. Pull the hose out fully, and engage the latch. extended. Remove loops to decrease tension. 2.
Page 12 Maintenance Pressure Relief Procedure 4. Disconnect and remove the service hose. WARNING 5. Attach the hose (48) to the hose reel swivel (34), and carefully remove the C-clamp. See Fig. 13. SKIN INJECTION HAZARD To reduce the risk of serious injury, including fluid injection, splashing in the 6.
Page 13 Maintenance Lubrication Every six months, apply one or two drops of light motor oil to lubricate the hose reel at point A. See Fig. 14. 03722 Fig. 14 308400...
Page 14 Service Swivel 1. Relieve the pressure. WARNING SKIN INJECTION HAZARD To reduce the risk of serious injury whenever you are instructed to relieve pressure, always follow the Pressure Relief Procedure on page 12. PACKING DETAIL 1645 Lubricate cavity with grease Lips of v-packings MUST face reel flange O-ring MUST be cradled...
Page 15 Notes 308400...
Page 16 Parts List – Low/Medium Pressure Medium Pressure Hose Reels Low Pressure Hose Reels Model 238213, Series E Model 237020, Series D Hose reel with 60 ft (18.3 m),180 psi (1.25 MPa, Bare Hose Reel, 1800 psi (124 MPa, 124 bar) 12.5 bar) hose Includes items 1 to 41 Includes items 1 to 45 and 52...
Page 17 Parts Drawing – Low/Medium Pressure 49, 52, or 53 Ref 49, 52, or 53 38 7 Use at least one washer (21) here Use four washers here .030 maximum clearance 03715 Torque to 25–35 ft. lbs. 05390E Detail for Placement of Washers (21) Torque to 85–105 ft.
Page 18 Parts List – High Pressure Model 237030, Series D Model 256997, Series D Bare hose reel Hose reel with 50 ft (15.2 m), 5000 psi (34.5 MPa, Includes 4 to 46 345 bar) hose Includes items 1 to 47, 49 Model 237032, Series D Model 237034, Series D Hose reel with 50 ft (15.2 m), 5000 psi (34.5 MPa,...
Page 19 Parts Drawing – High Pressure 49 or 52 47 or 51 Ref 49 or 52 38 7 05392F Use at least one washer (21) here 03713 Use four washers here .030 maximum clearance Torque to 25–35 ft. lbs. Detail for placement of washers (21) Torque to 85–105 ft.
Page 20 Accessories – Mounting Must be purchased separately. Use only genuine Graco parts and accessories. Order mounting hardware as needed per items 1 and 2 below. Mounting Bracket 204741 Mounting Channels Secures mounting channel to I-beam without holes For mounting open hose reels to ceiling. Includes drilled in I-beam.
Page 21 Accessories Hose Inlet Kits High-Pressure Reels 218550 Low-Pressure Reels 218549 Includes items 402–403 Includes items 402–403 Ref. Part No. Description Qty. Ref. Part No. Description Qty. 157416 UNION, 90_; 1/2 npt(f) x 1/2 npsm (f) swivel 214601 HOSE, fluid, buna-N; 1/2” ID; cpld 155677 UNION, 90_;...
Page 22 Notes 308400...
Page 23 Technical Data Dimensions Low-Pressure Hose Reels, Bare Reel Inlet ....... . 1/2 npsm(m) Outlet .
Page 24 With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
