Installation
Figure 16. Top and Bottom Entry Conduit and Wire Entry Locations
Access plate for
Service use only.
**Not to be used for
conduit routing**
Top Entry Conduit
Landing for DC Output /
Interface wiring
(Remove panel to drill
or punch conduit holes.)
4 4 . . 4 4
I I n n s s t t a a l l l l i i n n g g I I B B C C – – S S W W I I n n t t e e r r f f a a c c e e W W i i r r i i n n g g
IBC–SWs can be installed in a line-up-and-match configuration with the interface wiring routed through the
IBC–SWs and UPS cabinet or in a standalone configuration with the interface wiring routed between the IBC–
SWs and the UPS cabinet using conduit.
4 4 . . 4 4 . . 1 1 I I n n s s t t a a l l l l i i n n g g B B a a t t t t e e r r y y D D e e t t e e c c t t I I n n t t e e r r f f a a c c e e C C o o n n n n e e c c t t i i o o n n s s
NOTE 1
NOTE 2
To install wiring:
1.
If wiring the IBC–SW battery detect interface terminals using line-up-and-match wiring using the inter-
cabinet wiring access pass-through (see
interface terminals using the top entry access, proceed to Step 5; if wiring the IBC–SW battery detect
interface terminals using the bottom entry access, proceed to Step 8.
NOTE
36
Eaton 93PM Integrated Battery Cabinet-Small Welded (IBC-SW) Installation Manual 164000639—Rev 03
Top View
Front
Disconnect terminal block plug from terminal block to wire plug.
If the inter-cabinet wiring access pass-through is not used to install the battery detect
interface wiring connections, conduit must be installed between the battery cabinet and
the UPS cabinet.
Figure
In multiple IBC–SW installations, route the battery interface wiring between IBC–SWs
through the top of the adjacent IBC–SW using the top side inter-cabinet access pass-
through (see
Figure
9).
Bottom View
Front
9) continue to Step 2; if wiring the IBC–SW battery detect
Bottom Entry Conduit
Landing for DC Output /
Interface wiring
(Remove panel to drill
or punch conduit holes.)
