- Page 1 NQKMQKOMNQ kÉï=~ë=çÑW== pfsfpflk=ÇáÖáí~ä léÉê~íáåÖ=áåëíêìÅíáçåë=OODD=jçåáíçê=^`I=obc=SQ=SR=OOU båÖäáëÜ Operating instructions for 22" monitor AC...
-
Page 2: Table Of Contents
Table of contents Sirona Dental Systems GmbH Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Table of contents General information....................Dear Customer, ..................... Contact data....................General information on the Operating Instructions ........Warranty and liability ..................Intended use .................... - Page 3 Sirona Dental Systems GmbH Table of contents Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Calling up the "Options" menu ..............4.4.1 Displaying monitor information............4.4.2 Moving the on-screen menu window..........4.4.3 Resetting to factory settings ..............
-
Page 4: General Information
1 General information Sirona Dental Systems GmbH 1.1 Dear Customer, Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital General information Dear Customer, You have decided to equip your dental treatment center with the integrated SIVISION digital communication system from Sirona. -
Page 5: General Information On The Operating Instructions
Sirona Dental Systems GmbH 1 General information Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 1.3 General information on the Operating Instructions General information on the Operating Instructions Observing the operating instructions Please familiarize yourself with the unit by reading through these Observing the operating instructions operating instructions before putting them into operation. -
Page 6: Intended Use
Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Intended use The 22" monitor AC is intended for use on dental units made by Sirona. It serves for viewing intraoral images and any other images resulting from the PC connection. -
Page 7: Safety Information
Sirona Dental Systems GmbH 2 Safety information Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 2.1 Identification of the danger levels Safety information Identification of the danger levels To prevent personal injury and material damage, please observe the warning and safety instructions provided in this document, which are... -
Page 8: Modifications And Extensions Of The System
2 Safety information Sirona Dental Systems GmbH 2.4 Modifications and extensions of the system Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Modifications and extensions of the system Modifications to this system which might affect the safety of the system owner, patients or other persons are prohibited by law. -
Page 9: Unit Description
Sirona Dental Systems GmbH 3 Unit description Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 3.1 Standards/approvals Unit description Standards/approvals The 22" monitor AC complies with the following standards: ● IEC 60950-1 (information technology equipment, e.g. PC) ● IEC 60601-1-2 (electromagnetic compatibility) This product bears the CE mark in accordance with the provisions of Directive 2006/95/EC of the European parliament. - Page 10 3 Unit description Sirona Dental Systems GmbH 3.2 Technical data Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Degree of protection Ordinary equipment (IP X0 – without against ingress of water: protection against ingress of water) Transport and storage Temperature: -20 °C –...
-
Page 11: Attachment And Connections
Sirona Dental Systems GmbH 3 Unit description Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 3.3 Attachment and Connections Attachment and Connections 100 mm 75 mm VESA DisplayPort HDMI 3,5 mm 100 – 240 V AC stereo audio 50/60 Hz 64 65 228 D3637 D3637.201.01.01.02 15.11.13... -
Page 12: Operation
4 Operation Sirona Dental Systems GmbH 4.1 Monitor operating concept Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Operation Monitor operating concept 4.1.1 Operating and display elements The monitor settings are made on the on-screen display (OSD, on-screen menu). -
Page 13: Displaying The On-Screen Menu And Selecting Settings
Sirona Dental Systems GmbH 4 Operation Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 4.1 Monitor operating concept 4.1.2 Displaying the on-screen menu and selecting settings In the on-screen menu, the settings are grouped into three menus "Brightness/Contrast", "Image Properties" and "Options". You can select the necessary settings from these menus. -
Page 14: Calling Up The "Brightness/Contrast" Menu
4 Operation Sirona Dental Systems GmbH 4.2 Calling up the "Brightness/Contrast" menu Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Calling up the "Brightness/Contrast" menu 1. Confirm the softkey for the [OK check mark]. The on-screen menu is displayed. -
Page 15: Adjusting The Contrast
Sirona Dental Systems GmbH 4 Operation Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 4.2 Calling up the "Brightness/Contrast" menu 2. Use the softkeys [Left arrow] and [Right arrow] to change the brightness value. Confirm by pressing the [OK check mark]. -
Page 16: Calling Up The "Image Properties" Menu
4 Operation Sirona Dental Systems GmbH 4.3 Calling up the "Image Properties" menu Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Calling up the "Image Properties" menu 1. Confirm the softkey for the [OK check mark]. The on-screen menu is displayed. - Page 17 Sirona Dental Systems GmbH 4 Operation Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 4.3 Calling up the "Image Properties" menu 2. Select the "Preset Mode" option to use preset RGB values. Select the "Custom" option to adjust the RGB values yourself.
-
Page 18: Selecting The Input Signal
4 Operation Sirona Dental Systems GmbH 4.3 Calling up the "Image Properties" menu Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 4.3.2 Selecting the input signal 1. Select the "Input Signal" setting and confirm by pressing the [OK check mark]. -
Page 19: Switching Scaling On/Off
Sirona Dental Systems GmbH 4 Operation Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 4.3 Calling up the "Image Properties" menu 4.3.3 Switching scaling on/off 1. Select the "Scaling" setting and confirm by pressing the [OK check mark]. 2. Select the "OFF(Original spect atio)"... -
Page 20: Calling Up The "Options" Menu
4 Operation Sirona Dental Systems GmbH 4.4 Calling up the "Options" menu Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Calling up the "Options" menu 1. Confirm the softkey for the [OK check mark]. The on-screen menu is displayed. -
Page 21: Moving The On-Screen Menu Window
Sirona Dental Systems GmbH 4 Operation Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 4.4 Calling up the "Options" menu 4.4.2 Moving the on-screen menu window 1. Select the "Menu Position" setting and confirm by pressing the [OK check mark]. -
Page 22: Resetting To Factory Settings
4 Operation Sirona Dental Systems GmbH 4.4 Calling up the "Options" menu Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 4.4.3 Resetting to factory settings 1. Select the "Factory Default" setting and confirm by pressing the [OK check mark]. -
Page 23: Changing The Time Before The On-Screen Menu Is Hidden
Sirona Dental Systems GmbH 4 Operation Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 4.4 Calling up the "Options" menu 4.4.4 Changing the time before the on-screen menu is hidden The time before the on-screen menu is hidden is preset to 10 seconds in the factory default settings. -
Page 24: Selecting A Digital Or Analog Audio Signal
4 Operation Sirona Dental Systems GmbH 4.4 Calling up the "Options" menu Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 4.4.5 Selecting a digital or analog audio signal 1. Select the "Audio source" setting and confirm by pressing the [OK check mark]. -
Page 25: Exit" Menu
Sirona Dental Systems GmbH 4 Operation Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital 4.5 "Exit" menu "Exit" menu The on-screen menu is automatically hidden if no keys are pressed for a certain period of time. This period of time prior to the menu being hidden can be adjusted, see "Changing the time before the on-screen menu is... -
Page 26: Care And Cleaning Instructions For The Practice Team
5 Care and cleaning instructions for the practice team Sirona Dental Systems GmbH 5.1 Care and cleaning agents Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Care and cleaning instructions for the practice team Care and cleaning agents NOTICE... -
Page 27: Disposal
Sirona Dental Systems GmbH 6 Disposal Operating instructions 22'' Monitor AC, REF 64 65 228 SIVISION digital Disposal Your product is marked with the adjacent symbol. Within the European Environmentally sound disposal Economic Area, this product is subject to Directive 2002/96/EC as well as the corresponding national laws. - Page 28 tÉ=êÉëÉêîÉ=íÜÉ=êáÖÜí=íç=ã~âÉ=~åó=~äíÉê~íáçåë=ïÜáÅÜ=ã~ó=ÄÉ=êÉèìáêÉÇ=ÇìÉ=íç=íÉÅÜåáÅ~ä=áãéêçîÉãÉåíëK «=páêçå~=aÉåí~ä=póëíÉãë=dãÄe=OMNM péê~ÅÜÉW ÉåÖäáëÅÜ mêáåíÉÇ=áå=dÉêã~åó aPSPTKOMNKMNKMNKMO NQKMQKOMNQ ûKJkêKW= MMM=MMM páêçå~=aÉåí~ä=póëíÉãë=dãÄe áå=íÜÉ=rp^W SQ=SR=OOU=aPSPT c~Äêáâëíê~≈É=PN páêçå~=aÉåí~ä=póëíÉãë=ii` lêÇÉê=kç aJSQSOR=_ÉåëÜÉáã QUPR=páêçå~=aêáîÉI=pìáíÉ=NMM `Ü~êäçííÉI=k`=OUOTP dÉêã~åó ïïïKëáêçå~KÅçã...
