Step-By-Step Instructions - Viewing Or Exporting Logs - Logicube Falcon-NEO User Manual

Details for the Logs screen can be found in
When using Drive to File mode (DD, E01, EX01, or DMG), log files are also stored in
the Destination drive in the same folder as the image files.
The log files in the Destination drive are available in PDF, HTML, and XML formats.
The log files may contain a "partial hash". This hash is for Falcon-NEO's internal
purposes only and cannot be validated by any other means. The partial hash is a
snapshot of the hash engine at the end of each segment file which the Falcon-
NEO can use to catch transfer errors and re-try if possible.
3.7.1 Step-By-Step Instructions – Viewing or Exporting Logs
1.
2.
3.
®
-Neo User's Manual
Logicube Falcon
Select Logs from the types of operation on the left side. A list of log files will
appear sorted by date (newest on top).
Select the log file to view by tapping the name of the log file. This will highlight
the log file chosen.
Tap the View icon to view the log file on-screen. The log files can also be
exported to a USB drive. To export the log files:
a. Connect a formatted USB drive (USB flash drive or USB external drive) to
one of the two USB ports located on the front of the Falcon-NEO.
The USB flash drive connected to the front
USB port must be formatted in Windows
using the NTFS, FAT32, or FAT file system.
b. Tap the Export icon to export the log file via USB. The log will be
exported/copied to the attached USB drive and will be in HTML, PDF, and
XML formats.
Section 5.7: Logs.
QUICK START
31
