  • Page 1 Installation manual 15 DC Inverter H...
  • Page 2 By following the suggestions contained in this manual, the product you have purchased will operate without problems, giving you optimum room temperatures with minimum energy costs. Innova S.r.l Compliance This unit complies with the following European Directives: •...

  • Page 3: Table Of Contents

    General General warnings ............. . . 1.

  • Page 4: General Warnings

    GENERAL General warnings After unpacking, check that the contents are intact Do not leave the room closed for long. Periodically and that all parts are included. If not, contact the agent open the windows to ensure proper ventilation. who sold the appliance to you. This instruction booklet is an integral part of the The appliance must be installed by an authorised appliance and, therefore, it must be kept with care...

  • Page 5: Description

    The air conditioning unit "2.0" is the new solution that Easy to install represents a significant step towards reducing the “2.0" can be installed on any perimeter wall either low or aesthetic impact of air conditioners. With a depth of just high. Everything needed for installation (template, support 16 centimetres, "2.0"...

  • Page 6: Handling

    Shipping dimensions and weight Shipping dimensions and weight Packaging M.E. 2.0 15 HP H2O Dimensions Weight 47,6 1.100 Supplied components The supply consists of the parts listed in the following table.

  • Page 7: Unit Parts

    GENERAL Unit parts Air outlet flaps Air Filter Touch screen display Anti-lifting bracket Front panel Room air probe Water entrance (Eurokonus M3/4") Power supply terminal block Outlet water (Euokonus M3/4") Decorative side panel Internal air intake grille Modulating valve kit 12 5...

  • Page 8: Installation Method

    INSTALLATION INSTALLATION Installation method Before installing the conditioner, it is essential to calculate Cover large windows exposed to sunlight with curtains the summer thermal loads (and winter ones for the or with external maskings (blinds, porches, reflecting models with a heat pump) of the room. The more exact films, etc.).

  • Page 9: Assembling The Unit

    INSTALLATION Assembling the unit To install the unit on a wall, drill 6 holes to attach the fixing The manufacturer cannot be held responsible for plate to the wall as indicated on the drilling template. The any underestimation of the structural consistency appliance weighs more on the right, so make sure to of the anchoring carried out by the installer.

  • Page 10: Condensation Drain Preparation

    INSTALLATION Condensation drain preparation For heat pump appliances, a condensation drain pipe (internal Ø16 mm, not supplied) must connect the unit to The hole for the condensation pipe must always slope the pipe on the rear of the appliance. towards the outside. A solenoid valve will start the flow of the condensation from the internal collection tray when the maximum level The exact position in which to place the pipe mouth is...

  • Page 11: Assembling Air Ducts And External Shutters

    INSTALLATION Mounting the appliance on the bracket After checking that the bracket is anchored to the wall and object. that all necessary electrical connections and condensation Once the work is done, check that there are no openings drain preparations have been made, you can mount the on the back of the appliance, especially where the air conditioner.
  • Page 12 INSTALLATION Hydraulic connections IMPORTANT the inverison of the intel/outlet connection can cause the appliance to malfunction and damage Hydraulic device to be integrated for safety As previously mentioned, the installer will have to provide below must be installed. some devices for the safety and correct maintenance of the appliance.

  • Page 13: Hydraulic And Chemical Characteristics Of Water

    INSTALLATION Hydraulic and chemical characteristics of water The internal water supply circuit has (as option) a two-way The KVS of the valve used is: modulating valve, driven directly from the interface by the Kv (m³ / h with Δp = 100kPa = 1bar) = 1.2 machine controller, which monitors the temperature of the water leaving the heat exchanger by regulating the flow of The general expression (valid for water or technically...

  • Page 14: Electrical Connection

    INSTALLATION Electrical connection The appliance is equipped with a power cable with plug It is possible to carry out the electrical connection using type F + E (CEE 7/7 schuko plug). a cable inside of the wall as indicated in the installation The cable can only be replaced by the manufacturer, template (recommended for installations in the upper part service center or qualified installer.
  • Page 15 INSTALLATION CP occupancy contact input connection When the CP contact opens (very low voltage, connected such as: open window contact, on/off remote, infrared to a free non-live contact) the appliance is put is stand-by presence sensors, enabling badge, etc. and CP appears on the display. We recommend using a double insulation cable.

  • Page 16: High/Low Installation Configuration

    INSTALLATION High/low installation configuration The unit can be installed either in the lower part (near the the room (coanda effect). floor) or in the upper part (near the ceiling) of the wall. In In this case, purchase the the lower cover decorative kit order to optimise air distribution and comfort, the direction code GB0737.

  • Page 17: Setting Cool Only Or Heat Only Modes

    INSTALLATION 2.10 Setting cool only or heat only modes It is possible to deactivate the heating or the cooling only) mode. modes following a simple procedure. Press the A key again to switch back to Ho (heating only) Keep the A key on the touch-screen display pressed for mode.
  • Page 18 MAINTENANCE Use of the appliance Objects or structural obstacles (furniture, curtains, The appliance must not be installed in rooms where plants, leaves, blinds, etc.) must not obstruct the normal explosive gases develop or where there are humidity air flow both from the internal and from the external grids. and temperature conditions that exceed the maximum levels reported on the installation manual.

  • Page 19: Maintenance

    MAINTENANCE MAINTENANCE Periodic Maintenance The air conditioner you have bought has been designed to only include the following cleaning operations: keep maintenance operations to a minimum, in fact, they External cleaning Disconnect the unit from the power supply before Pay attention to the sharp edges. each cleaning and maintenance intervention by setting the main power supply switch to off.

  • Page 20: Troubleshooting

    MAINTENANCE Troubleshooting In the even of a malfunction, please refer to the following table. If, please contact the authorised technical assistance. after performing the suggested checks, the problem is not solved, Fault Possible causes Solution Check there is power supply (by turning a light on, for example). Check that the thermal-magnetic circuit breaker used exclusively No power supply The appliance...

  • Page 21: Technical Specifications

    MAINTENANCE Technical specifications Please read data plate to obtain the technical data listed below. Power supply voltage Maximum absorbed power Maximum absorbed current Amount of refrigerant gas Casing protection rating 15 HP DC U.M. Inverter Technical specifications Cooling power (1) 2.96 Power in max cooling mod.
  • Page 22 NOTES...
  • Page 23 NOTES...
  • Page 24 INNOVA s.r. l . INNOVA s.r.l. Fraz . St rada, 16 - 38085 PIEVE DI BONO (TN) - ITALY Via I Maggio 8 - 38089 STORO (TN) - ITALY tel. +39.0465.670104 fax +39.0465.674965 tel. +39.0465.670104 fax +39.0465.674965 info@innovaenergie.com info@innovaenergie.com N420240A - Rev. 03...
