Chapter 5 Specifications

5.1 Specifications

Specification
Travel Range
Gear Reduction
Lead Screw Pitch
Feedback
Limit Switches
Motor Type†
Backlash
Axial Load Capacity
Speed Range*
Calculated Resolution‡
Phase to Phase Resistance
Phase to Phase Inductance
Operating Temperature
Cable Length
Connector
Compatible Controller
† Although thye motor drive voltage is nominally 6V, voltages up to 12V can be used
with PWM controlled outputs.
* At 2.6 mm/sec, velocity ripple and distortion of the acceleration/deceleration profile
may occur. For improved control, the max velocity should be limited to 2.3 mm/sec.
‡ Calculated Resolution. Actual resolution will depend on the applied load.
Rev 15 Aug 2018
Chapter 5 Specifications
Z806 Z812/Z812B
6 mm 12 mm
67:1
1.0 mm
Motor-mounted rotary encoder
512 counts/rev of the motor
34,304 counts/rev of leadscrew
Electromechanical
6 V DC Servo
<8 µm
9.0 kg
50 µm/sec to 2.6 mm/sec
29 nm
33.0 Ω
0.6 mH
41° to 104° F (5° to 40° C)
1.6 ft (0.5 m)
HDDB15
KDC101 K-Cube DC Servo Controller
Z825B
25 mm
