Operation and maintenance manual AQUAmax

General information on operation

The operation of the control unit takes place via three short-stroke keys. By pressing a key the
display illumination is switched on (lapses if no key is operated within 5 minutes).
Key functions:
↑↓ Scroll upwards or downwards / menu selection
OK Transition of cursor to the character, which is to be changed / value input is saved /
selection of menu point / menu setback.
With temperatures below 0°C a severely limited function of the LC display is to be anticipated.
©
The ATBcontrol 3 is supplied as plug-in variant. Cabling on site is dispensed with.
All tasks, which nevertheless require an opening of the control unit, are to be carried out by
a qualified electrician!
ATTENTION! Before opening the ATBcontrol
must be disconnected from the mains supply. Work on opened units may be
carried out exclusively by qualified electricians! Pay attention to phase-correct
connection (even with plug-in design)!
As you are concerned with an electrical plant with submerged motor units, a
separate B16 fuse and a (separate) upstream 30 mA ELCB (earth leakage circuit
breaker) is absolutely essential!
Attention is to be paid to correct laying of the protective earth conductor up to the
earthing of the building.
ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com /
Art.-No.: 9060 0210 / Status: 30.01.2019 / Page 9 from 40
®
BASIC/CLASSIC
©
3 and/or the connection box it/they
