  • Page 1 For a world with clean water PUROO / PUROO Complete ® ® Operating Instructions...

  • Page 3: Table Of Contents

    Please take a few minutes to read through this operating instruction closely and carefully. Only in this way is a secure and fault-free operation ensured. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 3 from 28...

  • Page 4: Functional Description Puroo

    With the removal of clean water, the water level is lowered to the minimum water level ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 4 from 28...
  • Page 5 With renewed rise of the water level to the maximum water level the plant to normal operation following removal of the clean water. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 5 from 28...

  • Page 6: Functional Description Puroo ® Complete

    Following the ending of the settling phase the compressed air elevator is again cleaned through several short conveying surges using treated wastewater before the actual clean water removal is applied. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 6 from 28...
  • Page 7 When the water level rises again to the maximum water level, the system returns to normal operation after clear water discharge. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 7 from 28...

  • Page 8: Control Unit Atbcontrol

    Nationally applicable specifications and technical data are to be observed! If the control unit is used for other applications without express approval of the firm ATB WATER GmbH and/or the following safety notices are disregarded, this can lead to malfunctions or defects in the plant.

  • Page 9: General Notes On Operation

    Attention is to be paid to the correct laying of the protective earth conductor up to the earthing of the building. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 9 from 28...

  • Page 10: Commissioning

    If the inputs are correct confirm with YES and OK. Changeover to the info indicator follows. Displayed are the selected PT number, the software version, time and serial number of the PUROO ® With this the commissioning is completed and the PUROO can start working.

  • Page 11: 1.2. Main Menu

    Indicated are the operation phase, the operational condition of the compressor, the remaining running time of the current operation phase, the elapsed time of the respective phase PUROO ® The last line shows the current time and the total operating hours of the aerator.

  • Page 12: Settings

    (in this case 60% after 6 hours). PUROO Complete ® Choice between the display of the settings and the recording of a completed sludge evacuation. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 12 from 28...

  • Page 13: Service Mode

    Inputs are not checked for plausibility. Our service department would be very happy to provide you with support. ATB WATER GmbH reject warranty claims of any kind for the results of incorrect inputs! 2.3.1 Settings (Service mode) Possibility for modification of preset parameters.
  • Page 14 5 hours). Also the lapse of time without clear water avacuation that must elapse before PUROO ® switching to economy mode (PUROO ® Complete). Complete ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 14 from 28...

  • Page 15: Manual Mode

    Select the desired language for menu management and display using the OK and ↑↓ keys and confirm with OK. Available are German English, French, Spanish, Polish and Dutch. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 15 from 28...

  • Page 16: Error Reset

    Before opening the control unit this must be disconnected from the mains supply. Work on opened equipment may be carried out exclusively by qualified skilled electricians! ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 16 from 28...

  • Page 17: Potential-Free Contact

    Accumulator: 2xNiMH, 1.2V, Type AA, 1,800 mAH; life: 1000 load/discharge cycles with trickle charge: min. 6 years | 25° with trickle charge: min. 3 years | 45° ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 17 from 28...

  • Page 18: Error Messages

    Membrane block blocked. Call Service. • Input 24 V Possible cause Rectification Check of the switched float inputs Call Service. negative. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 18 from 28...

  • Page 19: Uvs

    OK key (signal tone) for ca. 3 secs. If the voltage is re- established the signal deactivates automatically. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 19 from 28...

  • Page 20: List Of The Pre-Programmed Parameters

    ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 20 from 28...

  • Page 21: Info About The Puroo ® Complete Aeration Settings

    ® Info about the PUROO ® Complete aeration settings The continuously increasing sludge volume means in the PUROO ® Complete plant an increasing oxygen demand. Because the plant does not operate time- but inflow-controlled, the number of cleaning cycles give relatively precise conclusions about the wastewater inflow and therefore the sludge growth.
  • Page 22 Sludge volume Aeration intensity Schlammvolumen [ml/l] Belüftungsintensität [%] 1000 +100 + 75 + 50 + 25 T in Monaten Months ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 22 from 28...

  • Page 23: Notes On Scheduled Maintenance

    Lower water authorities often require the sending, by the operator or maintenance firm, of the scheduled maintenance reports following each maintenance period. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 23 from 28...

  • Page 24: Desludgement Specifics Puroo ® Complete

    ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 24 from 28...

  • Page 25: Ec Declaration Of Conformity

    Porta Westfalica, 04.04.2018 Markus Baumann (Managing Director) ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 25 from 28...
  • Page 26 Operating Instructions PUROO / PUROO Complete ® ® ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 26 from 28...
  • Page 27 ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: 9060 0271 / Status: 08.10.2021 / Page 27 from 28...
  • Page 28 Operating Instructions PUROO ® / PUROO ® Complete oCE / Art.-No.: 9060 0271 / Status: 08.10.2021...
