  • Page 1 Innovations for clean water ® PUROO Operation and Maintenance Manual...

  • Page 3: Table Of Contents

    Please take a few minutes to read through this operating instruction closely and carefully. Only in this way is a secure and fault-free operation ensured. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 3 from 32...

  • Page 4: Functional Description Puroo

    With the removal of clean water, the water level is lowered to the minimum water level ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 4 from 32...
  • Page 5 With renewed rise of the water level to the maximum water level the plant to normal operation following removal of the clean water. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 5 from 32...

  • Page 6: Control Unit Atbcontrol

    Nationally applicable specifications and technical data are to be observed! If the control unit is used for other applications without express approval of the firm ATB WATER GmbH and/or the following safety notices are disregarded, this can lead to malfunctions or defects in the plant.

  • Page 7: General Notes On Operation

    Attention is to be paid to the correct laying of the protective earth conductor up to the earthing of the building. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 7 from 32...

  • Page 8: Commissioning

    NO and OK. If the inputs are correct confirm with YES and OK. Changeover to the info indicator follows. Displayed are the selected PT number, the software version, time and serial number of the PUROO ® ® With this the commissioning is completed and the PUROO can start working.

  • Page 9: 1.2. Main Menu

    ® phase, the elapsed time of the respective phase PUROO The last line shows the current time and the total operating hours of the aerator. In the case of a fault the operating hours indicator switches with the fault report.

  • Page 10: Settings

    Inputs are not checked for plausibility. Our service department would be very happy to provide you with support. ATB Umwelttechnologien GmbH reject warranty claims of any kind for the results of incorrect inputs! 2.3.1 Settings (Service mode) Possibility for modification of preset parameters.
  • Page 11 Settings. 2.3.4.1. Serial number (Service mode) Possibility for amendment of the serial number. (Takes place from right to left.) ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 11 from 32...

  • Page 12: Manual Mode

    With a flooding alarm there is also an automatic reset following a drop of the float switch. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 12 from 32...

  • Page 13: Appendix Connection Board

    Before opening the control unit this must be disconnected from the mains supply. Work on opened equipment may be carried out exclusively by qualified skilled electricians! ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 13 from 32...

  • Page 14: Potential-Free Contact

    Accumulator: 2xNiMH, 1.2V, Type AA, 1,800 mAH; life: 1000 load/discharge cycles with trickle charge: min. 6 years | 25° with trickle charge: min. 3 years | 45° ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 14 from 32...

  • Page 15: Error Messages

    Membrane block blocked. Call Service. • Input 24 V Possible cause Rectification Check of the switched float inputs Call Service. negative. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 15 from 32...

  • Page 16: Uvs

    OK key (signal tone) for ca. 3 secs. If the voltage is re- established the signal deactivates automatically. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 16 from 32...

  • Page 17: List Of The Pre-Programmed Parameters

    ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 17 from 32...

  • Page 18: Notes On Scheduled Maintenance

    Lower water authorities often require the sending, by the operator or maintenance firm, of the scheduled maintenance reports following each maintenance period. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 18 from 32...

  • Page 19: Operator's Self-Monitoring

    Desludging can take place, also as required following consultation with the responsible water authorities and conclusion of a maintenance contract. ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 19 from 32...

  • Page 20: Notes On Disposal

    Collection points Wastes containing oil (oil filters, Poison wastewater Collection points clothes etc.) WC stones Poison wastewater Do not use ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 20 from 32...
  • Page 21 ® Operation and Maintenance Manual PUROO ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 21 from 32...

  • Page 22: Operations Diary

    Operation and Maintenance Manual PUROO Operations diary – Operator‘ self-monitoring Date Operating time Extraordinary incidents: Aeration [h] e.g. power failure, faults, sludge removal... ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 22 from 32...
  • Page 23 Operation and Maintenance Manual PUROO Operations diary – Operator‘ self-monitoring Date Operating time Extraordinary incidents: Aeration [h] e.g. power failure, faults, sludge removal... ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 23 from 32...
  • Page 24 Operation and Maintenance Manual PUROO Operations diary – Operator‘ self-monitoring Date Operating time Extraordinary incidents: e.g. power failure, faults, sludge removal... Aeration [h] ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 24 from 32...
  • Page 25 Operation and Maintenance Manual PUROO Operations diary – Operator‘ self-monitoring Date Operating time Extraordinary incidents: Aeration [h] e.g. power failure, faults, sludge removal... ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica, www.atbwater.com / Art.-No.: XXXX XXXX / Status: 08.02.2019 / Page 25 from 32...

  • Page 26: Ce Documentation

    NB 1739 ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica EN 12566-3:2016 Packaged domestic wastewater treatment plant for treatment of domestic wastewater ® PUROO Material Fibre concrete Effectiveness of the treatment: Efficiency of the treatment performance 95.1 % (with a certified organic daily pollutant load 97.9 %...
  • Page 27 NB 1739 ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica EN 12566-3:2016 Packaged domestic wastewater treatment plant for treatment of domestic wastewater ® PUROO Material concrete Effectiveness of the treatment: Efficiency of the treatment performance 93.8 % (with a certified organic daily pollutant load 96.6 %...
  • Page 28 NB 1739 ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica EN 12566-3:2016 Packaged domestic wastewater treatment plant for treatment of domestic wastewater ® PUROO Material PP (type G) Effectiveness of the treatment: Efficiency of the treatment performance 93.4 % (with a certified organic daily pollutant load 96.5 %...
  • Page 29 NB 1739 ATB WATER GmbH, Südstraße 2, D-32457 Porta Westfalica EN 12566-3:2016 Packaged domestic wastewater treatment plant for treatment of domestic wastewater ® PUROO Material PE (type A) Effectiveness of the treatment: Efficiency of the treatment performance 95.5 % (with a certified organic daily pollutant load 97.9 %...

  • Page 30: Ec Declaration Of Conformity

    Declaration of EC-conformity ATB Umwelttechnologien GmbH The manufacturer: Südstr. 2 D-32457 Porta Westfalica ® declares herewith, that the following PUROO specified product: 2006/42/EG Directive on machinery implements the requests of following EC- 2014/30/EU Directive to Directives: electromagnetic compatibility 2014/35/EU Directive to electrical...
  • Page 32 ® OM Manual PUROO / Art.-Nr.: XXXX XXXX / Status: 08.02.2019...
