Built with Anthro-DNA™
Components at a Glance
1
2
Front of Cabinet (closed)
1. Locking front door to User area.
2. Locking door latch w/padlock
bracket.
3. Feet (for countertop installation)
This Cabinet is designed to automatically charge and store tablet, smart phone, and hand-held devices
safely and efficiently. This cabinet supports 1-20 devices. Please review this manual before installing your
equipment to learn how to use the cabinet safely.
The cabinet is listed to UL Information Technology Equipment 60950-1 safety standard.
AC input: 120VAC 60 Hz. Max amps: 12A.
For the latest User Installation Guide please visit: www.ergotron.com
300-5620-00 rev. C 11/16
4
3
Front of Cabinet (open)
4. Lock mechanism
5. Bay dividers with
Cable Channels
6. Laptop cubby for host computer
Owner's Manual for
Yes 20 Charging Wall
Cabinet for Tablets
Part # YESCABGMPW
5
6
7
8
9
Side of Cabinet (open)
7. Cord pass-through from front
of cabinet
8. Center divider with power outlets
9. Power cord access
10. Locking side door to IT area
Table of Contents
Getting Started .............. 2
Safety Notices ............... 2
Installing the Cabinet .......3
Loading Devices ............ 6
Warranty ........................ 8
10
1 of 8
