SMC Networks Flow Sensor PFMV5 Instruction Manual page 3

Flow characteristic chart (Reference)
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0% 20%
PFMV5(05/10/30)F
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
-100% -50%
Refer to catalog for details of flow characteristic.
Piping
During installation of the flow sensor to the pipe, hold the body with specified
spanner
Tightening torque to mount the fitting is 1 to 1.5N
Recommended fitting list
PFMV5 series recommended fitting list
One-Touch fitting
• Male Connector (One-Touch Male Connector)/KQ2H04-M5
• Hexagon Socket head Male Connector/KQ2S04-M5
• Male Elbow/KQ2L04-M5
One-Touch mini fittings
• Male Connector/KJH04-M5
• Hexagon Socket head Male Connector/KJS04-M5
• Male Elbow/KJL04-M5
Miniature fitting
• Barb fittings for nylon tubing/M-5AN-4/M-5AN-6
PFMV5(05/10/30)
40% 60% 80% 100%
Maximum
rated flow
Flow
0% 50% 100%
Maximum
rated flow
Flow
. m
Mounting and Installation (unit: mm)
Mount on direct
Mount on both sides
L-type bracket
(Through hole)
L-type bracket
(Tapped)
Thread tightening torque is 0.32 0.02N•m.
Manifold mount (using ZS-36-A )
L-type bracket
(Tapped)
Thread tightening torque is 0.32 0.02N•m.
Depending on fittings, they interfere each other and not possible for mounting
in series by using bracket.
Circuit
Brown DC(+)
Black OUT (Analog output) 12 to 24VDC
1kΩ
Blue DC(-)
Analog output : 1 to 5V
Output impedance : Approx. 1kΩ
Mount on one side
Mounting screw
(M3 x 15L)
L-type bracket
(Tapped)
Mounting screw
Mounting screw
(M3 x 15L)
L-type bracket
(Through hole)
Mounting screw
Load
