- Page 1 SMC-520 TEMPERATURE & HUMIDITY SENSOR USER GUIDE SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu...
- Page 2 SMC Ship Motion Control is not responsible for any errors in this manual or their consequences. All rights reserved. SMC Ship Motion Control Ltd Email: info@shipmotion.eu Web: www.shipmotion.eu Tel: +46 8 644 5010 SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu...
-
Page 3: Table Of Contents
MAINTENANCE ........................15 SERVICE AND WARRANTY ....................15 5.1.1 ........................... 16 IABILITY 5.1.2 ....................17 ESTRICTION OF WARRANTY ........................17 ECHNICAL SUPPORT TECHNICAL SPECIFICATIONS SMC-520 ................. 18 FAQ AND SUPPORT......................19 SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu... -
Page 4: Introduction
1.1 RECEIVING THE TEMPERATURE AND HUMIDITY SENSOR Unpack the equipment and remove all the packaging materials and shipping carton. The SMC-520 sensor is delivered in a cardboard box designed to protect it from damage during transit. When the sensor has been received, it must be inspected for damage during shipment. If damage has occurred during transit, all the shipping cartons and packaging materials should be stored for further investigation. -
Page 5: Smc-520 Dimensions
1.2 SMC-520 DIMENSIONS All dimensions are in mm SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu... -
Page 6: Installation
SMC-560 Solar Radiation Shield 1.3.1 INSTALLATION LOCATION RECOMMENDATIONS Install the SMC-520 Temperature and Humidity sensor in an area with free air flow. Avoid positioning the sensor in position that would not be representative of the area to be measured. Where possible the sensor should be mounted away from heat sources, either direct such as exhausts or reflected such as building walls. -
Page 7: Mounting Instructions Using Solar Radiation Shield
Tighten the compression fitting to hold the sensor in place. It is normally enough to tighten the fitting by hand. After mounting in the shield connect the cable to the sensor. SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu... - Page 8 SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu...
-
Page 9: Electrical Communication
VDC+ Power input 12…30 VDC Note: Please pay special attention to the SMC-520 wire colours, as applying voltage to the data wires may damage the sensor. The serial communication over RS232 and RS485 can be configured for the following baudrates 4800, 9600, 19200, 38400 and 57600 bps from the SMC Configuration software. -
Page 10: Smc Instruments Configuration Software
The sensor is delivered from SMC with a set of default parameters which can be changed from the SMC IMU Configuration Software. The factory default communication settings are as follows. Baud Rate 38400 8 Databits No parity 1 stop bits SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu... -
Page 11: General Information Configuration Software
The software will read or re-read the sensor settings. Firmware update The sensor firmware can be updated from the configuration software. The update is done over RS232 serial communication and should only be updated with guidance from SMC. SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu... - Page 12 Commands such as changing the data output rate can be sent to the sensor via this input window. Terminal Use the check box to enable or disable the display of incoming data in the terminal window. Click on clear to clear the data in the terminal window. SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu...
-
Page 13: Serial Output Strings
Temperature in degrees, resolution 0.1° Unit ('C) Unit for temperature, 'C=Celsius, 'F=Fahrenheit 'K=Kelvin Termination Characters <CR><LF> Note: The Vaisala HMP155 string is a position based string and not comma separated SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu... -
Page 14: Configuration Commands
$xdrset,SMC Sets the name of the transducer in the WIXDR string 3.1 REPLIES FROM THE SMC-520 The sensor will reply with a confirmation when the command is accepted in the format as $upians,1 where the three first letters are identical to the command and the three last letters in the identifier are replaced with “ans”. -
Page 15: Maintenance
4 MAINTENANCE Filter The SMC-520 is equipped with a sintered teflon filter to protect the sensing elements from water and dirt. The filter which is located at the end of the sensor should be inspected periodically, every 6 to 12 months depending on the environmental conditions such as dust or exhaust emissions and replaced when necessary. -
Page 16: Liability
SMC shall not be bound by any representations or statements on the part of its employees or agents, whether oral or in writing, including errors made in catalogues and other promotional materials. Please read the SMC Ship Motion Control terms and conditions for complete information. SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu... -
Page 17: Restriction Of Warranty
If the Sensor is under warranty, repairs are free. Pack the sensor in its original packaging, or suitable heavy packaging. Mark the RMA# on the outside of the package Return the Sensor, prepaid carrier to SMC SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu... -
Page 18: Technical Specifications Smc-520
MTBF (computed) 50 000 hours IP66 Electrical Power requirements 12 - 30 VDC; 0.6 W Complies with the IEC 60945 Warranty & Support 2-year Limited Hardware & Software Warranty Free Technical & Hardware support SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu... -
Page 19: Faq And Support
If there is a chance that the baud rate has been changed and the Detect sensor button does not find the sensor, systematically check each baud rate option in the SMC sensor Configuration Software until the correct rate is found. SMC-520 User Guide revision 1.3 SMC Ship Motion Control www.shipmotion.eu...
