StructureScan Mini XT Quick Start Guide
4
Take a minimum of two survey lines in each direction and connect your marks to draw what is in the slab on the slab.
5
When you are finished with a survey line, select New or Close File from the Menu Carousel. The Mini XT will ask
you if you want to save the file. Click Left to save or Right to discard.
Note: GPR does not provide object size so GSSI recommends that you draw 2 inch (5 cm) thick line covering your
drawn markouts so as to provide a safe margin near any objects.
Direction of steel
2" (5 cm)
margin of
safety
Page 12
