PMA8000-SR Series Audio Selector Panel and Intercom System
1.6

EQUIPMENT SUPPLIED

1 ea. of the following units:
Model
PMA8000-SR
PMA8000-SR with option 1
PMA8000 Installation Kit: 250-880-0000
PMA8000-SR installation rack assembly
PMA8000-SR Rack back plate assembly w/coax
44-pin connector kit
Backshell, connector
Backshell Retainer
4 40 X 3/8 screw w/lock washer
4 40 X 7/16 screw w/nylon patch
4-40 Lock Nut
Solder Lug
Cable Clamp
#6-32 x ½" Flat head Philips screw
#6-32 Clip Nut
SIRIUS Satellite Antenna w/ cable
PMA8000-SR remote
1.7

EQUIPMENT REQUIRED BUT NOT SUPPLIED

a. Circuit Breaker: 1 ea; 5 amp PULL TYPE REQUIRED for PMA8000-SR
Speaker, 4 Ω
a)
b) Headphone Jacks (Stereo, as Required)
c) Microphone Jacks (as Required)
Headphones, 150 Ω (Stereo), up to 6 as required
d)
e) Microphones, up to 6 as required
f) Marker Antenna (75 MHz, VSWR <1:1.5, and appropriate for the airspeed)
g) Interconnect Wiring
1.8

Required Test equipment to check installation

Marker Beacon signal generator, such as:
a. IFR NAV401L, NAV402AP, IFR4000
b. TIC T-30D, T-36C
1.9

LICENSE REQUIREMENTS

None
1.8

SIRIUS SUBSCRIPTION REQUIREMENTS

The Sirius Satellite Receiver requires an activation and periodic subscription. Monthly, annual and lifetime
plans are available.
To activate the module, you will need to do the following:
•
Locate the SID/ESN number from your SIRIUS receiver in the PMA8000-SR (found on the unit
or played back, by pressing 4-1-1 with Sirius system turned on).
•
A major credit card.
•
The SIRIUS tuner installed, the aircraft outside with a clear view of the sky.
•
Turn your SIRIUS tuner on and tune it to channel 184.
200-880-0000
PS Engineering
Installation and Operator's Manual
Description
PMA8000-SR Audio Panel with Marker Beacon and Stereo
intercom.
Add Internal recorder to PMA8000-SR
Description
Page 1-4
Part Number
050-880-0100
050-880-0200
Quantity Part
Number
1 430-880-0040
1 010-880-1481
2 120-891-2045-
2 625-025-2465
2 431-881-0100
4 475-440-1038
4 475-440-0007
1 475-013-0001
1 475-009-0001
1 625-001-0002
6 475-632-0012
6 475-630-0002
1 510-880-0100
1 050-803-0200
Rev. 14, Oct. 2008
