Intercom Positions:
Music Inputs:
Music Muting:
Distortion:
Mic Freq. Response, 3 dB:
Music Freq. Response, 3 dB:
MARKER BEACON RECEIVER:PMA7000M-S only
Frequency:
Sensitivity:
Low:
High:
Selectivity:
External Lamp Output:
MM Sense:
1.6

EQUIPMENT SUPPLIED

1 ea. of the following units:
PMA7000M-S Installation Kit: 250-007-002
Part Number
001-006-0001
655-000-0001
200-070-0001
1.7

EQUIPMENT REQUIRED BUT NOT SUPPLIED

a) Circuit Breaker: 1 ea. 2 amp. (14V) or 3 amp (28V)
Speaker, 4 Ω
b)
c) Headphone Jacks (mono or stereo, as Required)
d) Microphone Jacks (as Required)
Headphones, 150 Ω (mono or stereo), up to 6 as required
e)
f) Microphones, up to 6 as required
g) Marker Antenna (75 MHz, VSWR <1:1.5, and appropriate for the airspeed)
h) Interconnect Wiring
1.8

LICENSE REQUIREMENTS

None
200-070-0006
PS Engineering
PMA7000M-S Series Audio Selector Panel and Intercom System
Installation and Operator's Manual
Intercom Specifications
Model
PMA7000S
PMA7000M-S
Description
Tray with (2) 44 Pin Connectors
Gold Plated Crimp Pins
Operator's and Installation Manual
Page 1-4
6 places (with individual IntelliVOX circuits)
2 (Stereo)
>-50 dB "Soft Mute" when Com or intercom ac-
tive.
<1% THD @ 38 mW into 150Ω
<10% THD @ 70mW into 150 Ω
300 Hz - 6000 Hz
100 Hz - 18kHz
75 MHz Crystal Controlled
1000 µVolts (Hard)
200 µVolts (Hard)
(Field Adjustable)
-6 dB at ±110 kHz
-40 dB at ±120 kHz
9.0 (±2.5 photocell dimmed) VDC positive when
active, max. current 125 mA
Active high (4.7 VDC ± 0.5V) during Middle
Marker acquisition, for autopilot use.
Part Number
7000S
7000M-S
Quantity
1
88
1
Rev. 6, Nov 98
