PS Engineering PMA8000-SR Owner's Manual page 35

PS Engineering
PMA8000-SR Audio Selector Panel and Intercom System
Installation and Operator's Manual
Figure 6-1 PMA8000-SR Installation Drawing
C a u t i o n : A p p l y s t e a d y p r e s s u r e t o t h e b e z e l w h i l e s c r e w i n g t h e u n i t i n t o t h e t r a y t o
e n s u r e e v e n s e a t i n g o f t h e u n i t a n d c o n n e c t o r s .
2.00 in
2.38 in
Antenna Coax, 20'
Supplied
0.54 in
Figure 6-2 SIRIUS Antenna Drawing
200-880-0000 Appendix B Rev. 14, Oct. 2008
