LDC401 & LDC401A Automated Cleavers
Chapter 4
Set-up
4.1.

Initial Set-up

1.
Plug in the AC power cord. The power supply
accepts an AC input of 100 - 240 VAC; 47 -
63 Hz.
2.
Connect the AC power cord to the external
power supply.
3.
Connect the DC power cable to the unit.
4.
Locate the USB cable that has a microUSB Type
B plug. Plug it into the power socket of the tablet.
Page 6
Chapter 4: Set-up
TTN100064-D02
